14 Part Number STH044 10/13
Ice Machine Clearance Requirements
Ice Machine Heat of Rejection
Ice machines, like other refrigeration equipment, reject
heat through the condenser. It is helpful to know the
amount of heat rejected by the ice machine when
sizing air conditioning equipment where self-contained
air-cooled ice machines are installed.
RNS012 - RNS020 Self-Contained Air-Cooled
Top 24" (61.0 cm)
Sides 8" (20.3 cm)
Back 5" (12.7 cm)
RNS012 - RNS020 airflow is in the left side and out the top.
Series
Ice Machine
Heat of Rejection*
Air Conditioning
RNS012 - RNS020 2,300
* BTU/Hour
Because the heat of rejection varies during the ice making cycle,
the figure shown is an average.
