82 Part Number STH044 10/13
DISPENSE SWITCH
FUNCTION
Supplies power to the product selector switch when
activation lever is depressed.
CHECK
1. Inspect the selector switch for correct wiring.
2. Isolate the switch by disconnecting all wires from
the switch.
3. Check across the switch terminals with an ohm
meter.
Replace the selector switch if ohm readings do not
match.
Activation Lever Position Resistance Reading
Depressed Closed
Released Open
