Manitowoc Shuttlelift CD5520

Grove Published 07-06-2017, Control # 406-03 6-7
CD5520/YB5520 OPERATOR MANUAL MAINTENANCE
6
FIGURE 6-3
p0389
Lube Both Sides.
Boom Head Sheaves and Pivot
Lube Points
p0390
Lube Both Sides on Both Ends.
FIGURE 6-4
Lift Cylinder Pivots Lube Points
FIGURE 6-5
p0417
Steering Knuckle Lube Points
(Front Axle)
FIGURE 6-6
p0421
Steering Knuckle Lube Points
(Rear Axle)
FIGURE 6-7
p0419
Steering Link Lube Points (Front
Axle)
Lube Both Sides.
Reference Only
