RDE 92703-02-R/12.00
Reparaturanleitung A10V(N)O
Repair Instructions A10V(N)O
Brueninghaus Hydromatik 11
Triebwerk ausbauen
Remove rotary group
Lager und Scheibe ausbauen.
Dichtfläche nicht beschädigen.
Remove bearing and shim.
Do not damage the sealing surface.
Lager der Anschlußplatte mit Abzieher
ausbauen.
Dichtfläche nicht beschädigen.
Pull bearing of the connection plate out using
a bearing puller.
Do not damage the sealing surface.
Triebwerk in horizontaler Lage herausziehen.
Remove the rotary group in a horizontal
position.
