RDE 92703-02-R/12.00
Reparaturanleitung A10V(N)O
Repair Instructions A10V(N)O
Brueninghaus Hydromatik 7
Steuerventil abbauen
Maß * festhalten!
Dichtfläche (1) kontrollieren.
O-Ringe (2) kontrollieren.
Remove the control valve
Measure dimension * and note
down!
Check sealing surface (1).
Check O-rings (2).
*
Steuerventil abdichten / reinigen
Sealing / cleaning the control valve
1
*
2
