RDE 92703-02-R/12.00
Reparaturanleitung A10V(N)O
Repair Instructions A10V(N)O
Brueninghaus Hydromatik 9
Steuerventil abbauen.
Remove the control valve.
Pumpe demontieren
Disassemble the pump
Demontageposition
Lage der Anschlußplatte zum Gehäuse der
Pumpe kennzeichnen.
Disassembly position
Mark the location of the connection plate
on the housing of pump.
