RDE 92703-02-R/12.00

Reparaturanleitung A10V(N)O

Repair Instructions A10V(N)O

Brueninghaus Hydromatik 5

Triebwelle abdichten

Sealing the drive shaft

Triebwelle abkleben.

Sicherungsring ausbauen.

Wellendichtring nach vorne entnehmen.

Protect the drive shaft.

Remove the circlip.

Remove shaft seal to front.

1. Sicherungsring, 2. Wellendichtring, 3. Lager

1. Circlip, 2. Shaft seal, 3. Bearing
