Reparaturanleitung A10V(N)O
Repair Instructions A10V(N)O
RDE 92703-02-R/12.00
16 Brueninghaus Hydromatik
Pumpe montieren
Pump assembly
Lageraußenring mit Vorrichtung einpressen.
Press-in distance ring with tool.
Welle in Lager einstecken.
Wellendichtring nicht beschädigen!
Assemble shaft in correct position.
Do not cut shaft seal!
