Key Qty. Part No. Description 1 1 430004 Trigger Handle Assembly, 4 Cycle Engine, Right 2 1 430006 Handle Assembly, Left 3 1 430053 Middle Handle W/Plug, Right 4 1 430052 Middle Handle W/Plug, Left 6 1 430051 Lower Handle W/Plug, Right 7 1 430050 Lower Handle W/Plug, Left 8 1 430021 Handle Brace 9 1 400638 Label, Handle Brace 10 1 430023 Loop Handle Right Half 11 1 430022 Loop Handle Left Half 12 1 910502 10-32 X 3/4” Flange Bolt 13 2 478 Throttle Clip 14 2 430025 Foam Grip 15 1 430049 Carry Handle W/Grip 16 2 4049 Bolt 1/4-20 X 3.25” 17 2 430038 Knob, 1/4-20 X1.5 Male 18 1 4078 M6 Jam Nut 19 2 430048 Curved Head Bolt, 1/4-20 X2” 20 1 400312 Fender Guard 21 1 400916 Engine Assembly-35cc Honda
®
22 1 468 Drive Shaft 23 1 400301 Worm Gear Housing 24 1 436 Gasket 25 1 437A Gear Housing Cover 26 4 651 #8 Self Tapping Screw 27 1 423 Roller Bearing 28 2 425 Worm Bearing Race 29 1 424 Worm Thrust Bearing 30 1 422 Worm Shaft 31 1 426 Worm Disk 32 1 428 Retaining Ring 33 1 429 Worm Gear 34 1 431 Tine Shaft
Key Qty. Part No. Description 35 2 430 Worm Gear Thrust Washer 36 2 432 Worm Gear Bearing 37 2 434 Bearing 38 2 435 Bearing Seal Retainer 39 1 400328 Tine Assembly, Outer Right 40 1 400327 Tine Assembly, Outer Left 41 2 418-1 Tine Retaining Pin 42 2 430039 Carriage Bolt 1/4-20 X 2.25” 43 1 400307 Engine Flange 44 1 400631 Triangle Warning Label (4 Cycle Engine) 45 1 458 Roller Bearing 46 1 430058 Mantis Logo Label 47 2 395 Acorn Nut 48 6 972 1/4-20 Two-Way Lock Nut 49 4 144-2 1/4-20 X 1.125 Hex Head Cap Screw 50 2 M9452 Bolt 1/4-20x1/2” Long 51 1 430057 Warning Label 52 1 400302 Transmission Assembly* 53 4 400523 Knob, Two Prongs, Female 54 1 430043 Ground Wire Jumper, 4 Cycle Engine 55 1 4079 M6 Internal Lock Washer 56 1 400132 Bearing 57 1 400308 Clutch Drum 58 4 400529 M6x33mm Flange Bolt 59 1 410158 Kickstand, Stand Assembly 60 1 430037 Kickstand, Bracket And Hardware 61 1 400524 Retaining Ring 62 1 400310 Throttle Stop, Honda
®
34cc
64 1 400313 Dust Cap for Grease Fitting 65 1 400300 Grease Fitting 66 1 400330 Tine Assembly, Inner Right 67 1 400329 Tine Assembly, Inner Left 69 2 400635 Label XP Tine Warning 70 1 400310 Throttle Stop
* Includes Key #22
