1600/1800 Manual
2. Place the instrument (Fig.1-3) in a suitable location away from direct sunlight.
In order to have the best performance from your instrument, keep it as far as
possible from any strong magnetic or electrical fields or any electrical device that
may generate high-frequency fields. Set the unit up in an area that is free of
dust, corrosive gases and strong vibrations.
Fig.1-3
3. Remove any obstructions or materials that could hinder the flow of air under and
around the instrument.
4. Use the appropriate power cord and plug into a grounded outlet.
Fig.1-4
5. Turn on your MAPADA UV/V-1600/1800 model spectrophotometer. Allow it to
warm up for 20 minutes before taking any readings. We suggest you then do the
Calibrate System with the Search 656.1nm to set the wavelength to the
deuterium lamp emission line.
NOTE:
This symbol means Caution, Risk of Danger.
Control Panel
LCD
Compartment
Holder Changer Knob
Fan
Parallel Port USB Port
Power Cord Inlet
Fuse
Power Switch
