1600/1800 Manual
ensure that you have received everything in good condition.
Packing List
Description Quantity
Spectrophotometer ............................................................... 1
Mains Lead ........................................................................... 1
Cuvettes ................................................................................ Set of 4, glass
.......................................................................... Set of 2, quartz
Manual .................................................................................. 1
Note: the Quartz cuvette does not come standard with the model of V1600 and v1800..
Specifications:
Installation:
1. After carefully unpacking the contents, check the materials with the packing list
(page 2) to ensure that you have received everything in good condition.
Model V-1600 V-1800 UV-1600 UV-1800
Wavelength Range 320-1100nm 190-1100nm
Spectral Bandwidth 4nm 2nm 4nm 2nm
Optical System Single Beam, Grating 1200lines/mm
Wavelength Accuracy ±0.5nm
Wavelength Repeatability 0.3nm
Wavelength Resolution ±0.1nm
Photometric Accuracy ±0.3%T
Photometric Repeatability ±0.2%T
Photometric Range -0.3-3A, 0-200%T
Stray Light 0.05%T@360nm 0.05%T@220nm,340nm
Stability ±0.002A/h @500nm
Display Graphic LCD (128X64 dots)
Keyboard 22 Membrane keypad
Photometric Mode T, A, E
Detector Si Photodiode
Sample Compartment
Standard 10mm path length cuvette
Accommodates 100mm path length cuvette with optional holder
Light Source Tungsten lamp Tungsten & Deuterium
Output USB Port Parallel Port (printer)
Power Requirement AC 220V/50Hz or 110V/60Hz
Dimensions (W x D x H) 470 x 370 x 180mm
Weight 12kg 14kg
