DESIG. PART NO. DESCRIPTION DESIG. PART NO. DESCRIPTION
C501 DK1710301 | Ceramic,O.01uF, +20%, YY CAPACITORS
C502 DK1840302 | Ceramic,0.04uF, +100%, -0% C551 DD1615001 | Ceramic, 15pF, +10%, SL
C503 EA1060169 | Elect., 10uF, 16V C552 DF 1668301 | Ceramic,0.068uF, +10%
C504-C505 | DK1840302 | Ceramic,0.04uF, +100%, —0% C553 DF1740301 | Mylar, O.04uF, +20%
C506-C507 | DD1620101 | Ceramic, 200pF, +10%, SL C554 EA1060162 | Elect., 10uF, 16V
C508 EA1060169 | Elect., 10uF, 16V C555 DK1840302 | Ceramic,0.04uF, +100%, —0%
C509 EA1070109 {| Elect., 100uF, 10V C556-C558 | DK1810402 | Ceramic, 0.1uF, +100%, —0%
C510 ED1050501 | Elect., 1uF, 50V C560-C561 | DK1710301 | Ceramic,0.01uF, +20%,
C511
EA1060169
|
Elect.,
10uF,
16V
C562
DK1840302
|
Ceramic,0.04uF,
+30%,
—20%
C512 DK 1840302 | Ceramic,0.04uF, +100%, —0% C559 EA1060162 | Elect., 10uF, 16V
SEMICONDUCTORS
C513 DD1620101 | Ceramic, 200pF, +10%
C514 EA1070169 | Elect., 100uF, 16V H551 HT307331C | Transistor, 2SC733GR
C515 DK1710301 | Ceramic,O.01uF, +20% H552-H553 | HT3037210 | Transistor, 2SC372
C516-C517 | DK1840301 | Ceramic,0.04uF, +100%, —0% H554-H555 | HD1000105 | Diode, 1N60
C519 DK1840301 | Ceramic,0.04uF, +100%, —0% H557 HD 1000105 | Diode, 1N60
H558
H559-H561
HF 200300A
HT3037210
C520 DK1840302 | Ceramic,0.04uF, +100%, —0% FET, 2SK30, GR
Transistor, 2SC372
SEMICONDUCTORS
H501 HC1000209 | IC, NJ703W MISCELLANEOUS
H502 HT306441B | Transistor, 2SC644S L551 LC2105001 | Choke Coil, ImH
H503-H504 | HD1000105 | Diode, 1N60
J551-J555 YP1000094 | Plug
MISCELLANEOUS J557 YP 1000094 | Plug
J501-J509 YP1000094 | Plug J559-J566 YP1000094 | Plug
L501 L11018801 | IFT, FM Det. P400 YD2577004
(ZZ2577004)
P.C. Board for Pre and Tone Amp.
P.C. Board Assembly
P550 YD2818006
(ZZ2818006)
P.C. Board for Noise DC Amp.
P.C. Board Assembly RESISTORS
Carbon, 3902, 410%, 1/4W
Carbon, 150KQ, +10%, 1/4W
R401-R402
R403-R404
RT 1039114
RN1015414
RESISTORS
R551 RT1056214 | Carbon, 5.6KQ, +10%, 1/4W R450-R406 | RN1010414 | Carbon, 100K, +10%, 1/4W
R552 RT1010114 | Carbon, 10022, +10%, 1/4W R407-R408 | RN1022314 | Carbon, 22KQ, 410%, 1/4W
R553 RT1027314 | Carbon, 27KQ, +10%, 1/4W R409-R410} RN1027314 } Carbon, 27KQ, +10%, 1/4W
R554 RT1010414 | Carbon, 100K2, +10%, 1/4W R411-R412 | RT0520214 | Carbon, 2KQ, 45%, 1/4W
R555 RT1010214 | Carbon, 1KQ, 410%, 1/4W R413-R414 | RT1010214 | Carbon, 1KQ, 410%, 1/4W
R556-R557 | RT1033314 | Carbon, 33KQ, +10%, 1/4W R415-R416 | RT0510314 | Carbon, 10KQ, 1b%, 1/4W
R559 RT1033314 | Carbon, 33KQ, £10%, 1/4W R422-R423 | RN1022514 | Carbon, 2.2MQ, 410%, 1/4W
R560-R561| RT1033214 | Carbon, 3.3KQ, £10%, 1/4W R424-R425 | RN1068314 | Carbon, 68K{2, 410%, 1/4W
R562 RT1018414 | Carbon, 180K2, +10%, 1/4W
R563-R564} RT1010114 1002, +10%, R426-R429
R430-R431
RN 1010314
RT0522114
Carbon, Carbon, 10KQ, +10%, 1/4W
Carbon, 220022, 15%, 1/4W
R565 RT1015314 | Carbon, 15KQ, +10%, 1/4W
R566 RT0533414 | Carbon, 330KQ2, +5%, 1/4W CAPACITORS
R568 RT1022214 | Carbon, 2.2KQ, +10%, 1/4W C401-C402 | DF1722402 | Mylar, 0.22uF,50V,+20%
R569 RT0510314 | Carbon, 10KQ, +5%, 1/4W C403-C404 | EV1050251 j Elect, 1uF, 25V,4+40%, —20%
R571 RT0527414 | Carbon, 270KQ2, +5%, 1/4W C405-C406 | EA1060359 | Elect., 10QuF, 35V,+100%, —0%
R572 RT1010114 | Carbon, 1002, £10%, 1/4W C407-C408 | EV3350251 | Elect, 3.3uF, 25V,+40%, —20%
R573 RT0515314 | Carbon, 15KQ, +5%, 1/4W C409 EA1070359 | Elect., 100uF, 35V,+100%, —0%
R574 RT0512314 | Carbon, 12KQ, +5%, 1/4W C410-C411 | £V3350251 ] Elect., 3.3uF, 25V,+40%, —20%
R576 RT0510314 | Carbon, 10KQ, +5%, 1/4W C414-C415 | EV1050351 | Elect, iF, 35V,+40%, —20%
R577 RT1022114 | Carbon, 220KQ, +10%, 1/4W
SEMICONDUCTORS
Transistor, 25C 1000 Gror B1
Transistor, 2SA493 Yor Gr
Transistor, 25C1000 Gr or B1
R578
RT1010114
Carbon, 1000, +10%, 1/4W H401-H402
H403-H404
H405-H406
HT310002A
HT 104932A
HT310002A
29
