Connecting 13.1-channel speakers : Second pair of front speakers
This system enables switching playback between front speakers A and B
as desired.
C
SW
RSLS
FHL FHR
RHL RHR
SBL
SBR
FL
(A)
FL
(B)
FR
(B)
FR
(A)
TML TMR
GExampleH UNBALANCED RCA connector connection
SR SLC RHR RHL TMR TMLFHR FHL
SW1
SBLSBR
Marantz
AMP 10
z
2
z
2
z
1
z
1
z
2
z
2
z
2
z
2
FR
(A)
FL
(A)
FR
(B)
FR
(B)
z1
The PRE OUT connectors for connecting to the second front speakers vary
depending on the main zone layout. Refer to “Amp Assign” - “Front B”.
(v p. 224)
z2
The height speakers, ceiling speakers and Dolby Atmos Enabled speakers
can be connected to the HEIGHT1, HEIGHT2 and HEIGHT3 RCA connectors
or HEIGHT1, HEIGHT2 and HEIGHT3 XLR connectors. Set the speaker to be
connected from “Height” in the menu. (v p. 218)
