Marantz CD5005 - Page 64

FRONT
FRONT PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D1 00D9600095607 DIODE , ZENER ,1/2W, 5.6V CVDZJ56BT 1
D3111,3112 00D9430182609 DIODE , SWITCHING CVD1SS133MT 2
D3601 90M-HI200020R INFRARED LED U BVDSIR34ST3F 1
D3602 00D9430182609 DIODE , SWITCHING U CVD1SS133MT 1
D3901 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D3904 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D3905 90M-HD302350R DIODE , ZENER ,1/2W, 27V CVDZJ27BT 1
D3906 90M-HD302480R DIODE , ZENER ,1/2W, 15V CVDZJ15BT 1
D3911-3913 00D9430182502 DIODE , RECT CVD1N4003ST 3
D3916 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D3918 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D3919 00D9430182502 DIODE , RECT CVD1N4003ST 1
D3929-3931 00D9430182502 DIODE , RECT CVD1N4003ST 3
D3933 00D9600095607 DIODE , ZENER ,1/2W, 5.6V CVDZJ56BT 1
D3934 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D3935 919202500600D DIODE , ZENER ,1/2W, 11V CVDZJ11BT 1
D3936-3939 00D9430182502 DIODE , RECT CVD1N4003ST 4
D3949,3950 00D9430182502 DIODE , RECT CVD1N4003ST 2
D3953-3956 00D9430182502 DIODE , RECT CVD1N4003ST 4
D4001 90M-HI101040R LED , RED HVD342VCTB7T089 1
D4101 90M-HI101040R LED , RED HVD342VCTB7T089 1
IC61 00MHC10102090 IC , OP AMP (JRC) HVINJM2068MDTE1 1
IC71 00MHC10102090 IC , OP AMP (JRC) HVINJM2068MDTE1 1
Q3110-3113 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 4
Q3114,3115 00D9430072502 TR , CHIP , SOT-23 HVTKTC2875B 2
Q3116 943219500200M TR , CHIP , SOT-23 HVTKRC104S 1
Q3117 00D2690191903 TR , CHIP , SOT-23 HVTKRA104S 1
Q3118 943219500200M TR , CHIP , SOT-23 HVTKRC104S 1
Q3120-3123 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 4
Q3214,3215 00D9430072502 TR , CHIP , SOT-23 HVTKTC2875B 2
Q3301 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3302,3303 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q3304 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3401 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3402,3403 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q3404 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3601 943215500140D TR,RT1P144C(10K-47K) U CVTRT1P144C 1
Q3901 943219006820S TR CVTKTC1027YT 1
Q3902,3903 90M-HX800090R TR , CHIP , SOT-23 HVTKRC111S 2
Q3904,3905 00D9430154404 TR HVTKTC3198YT 2
Q4001 00D9630121606 TR , CHIP , SOT-23 HVTKRC107S 1
Q4002 00D2690184907 TR , CHIP , SOT-23 HVTKRA102S 1
Q4102 00D2690184907 TR , CHIP , SOT-23 HVTKRA102S 1
Q4301 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q4302,4303 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q4304 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q4305,4306 00D9430072502 TR , CHIP , SOT-23 HVTKTC2875B 2
Q4401 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q4402,4403 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q4404 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q4405,4406 00D9430072502 TR , CHIP , SOT-23 HVTKTC2875B 2
U3601 262010007707S REMOTE SENSOR , R94EV1A U CRVR94EV1A 1
U3901 231310009508S IC , REGULATOR (33V) CVIPQ033DNA1ZPH 1
U3902 nsp IC HEATSINK ASS'Y(CMY2A223) CVIKIA7812APIJA 1
U3903 00D9430198304 IC , REGULATOR HVINJM7806FA 1
U3904 943239010400S IC, REGULATOR(33V/TO-252) CVINJM2845DL133 1
U3905 nsp IC HEATSINK ASS'Y (CMY2A223) CVIKIA7912PIJA 1
U3906 943219500140M IC, REGULATOR(50V/TO-252) CVINJM2845DL1-05 1
! U3907 00MHC3890599F IC,REGULATOR(+5V,T0220IS) HVIKIA7805API 1
U4001 262010007707S REMOTE SENSOR , R94EV1A CRVR94EV1A 1
U4003 943172100160S VFD (FUTABA, 16ST103GINK) CFL16ST103GINK 1
RESISTOR GROUP
R1,2 nsp WIRE, COPPER(D06) C3A206 2
R5,6 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7-10 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
R11,12 nsp WIRE, COPPER(D06) C3A206 2
R15,16 nsp WIRE, COPPER(D06) C3A206 2
R19 nsp RES, CARBON(1/5W,27Kohm,J) CRD20TJ272T 1
R21 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R606 nsp RES, CARBON(1/5W,750ohm,J) CRD20TJ751T 1
R706 nsp RES, CARBON(1/5W,750ohm,J) CRD20TJ751T 1
R3101-3106 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 6
R3109,3110 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ472T 2
R3111 nsp RES, CARBON(1/5W,27Kohm,J) CRD20TJ272T 1
R3112 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ472T 1
R3113 nsp RES, CARBON(1/5W,27Kohm,J) CRD20TJ272T 1
R3114 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ472T 1
R3115 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R3117 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R3121,3122 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 2
R3123,3124 nsp RES, CARBON(1/5W,100ohm,J) CRD20TJ101T 2
R3125 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R3126 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3127 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ222T 1
R3128 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R3129 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3130 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ222T 1
R3131 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3132 nsp RES, CARBON(1/5W,100ohm,J) CRD20TJ101T 1
R3133 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R3213-3216 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T 4
R3217,3218 nsp RES, CARBON(1/5W,39Kohm,J) CRD20TJ392T 2
R3219 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T 1
R3220,3221 nsp RES, CARBON(1/5W,39Kohm,J) CRD20TJ392T 2
R3222-3224 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T 3
R3225 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R3226 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3227 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ222T 1
