MAIN
MAIN PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D1 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D100 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D300-304 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 5
D308 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25 1
IC100 943245006980S I.C , CD DSP(DSP,LQFP-80P) CVITC94A92FG_CU 1
IC101 943239006900S I.C , 5-CH MOTOR DRIVE(REG,SSOP-28P) CVIIP4001CRLTF_CN 1
IC103 943231101630S I.C REGULATOR 1.5V LDO,SOT-223 CVILM1117C-1V5 1
IC25 943231101900S I.C REGULATOR 1.8V LDO,SOT-223 CVILM1117C-1V8 1 *
IC26 00D2623489909 I.C , INVERTER(CMOS) CVITC7WHU04FU 1
IC27 943235002460S I.C , PLL(TSSOP-14) CVICDCE913PWR 1
IC300 943246100770D I.C , EEPROM (16KBIT,SOP-8P,K-Line) CVIK24C16BSIRGA 1
IC301 943234009290S I.C , RESET 2.4V (200ms,C-MOS,SOT23-5P) CVIS80124CLMCJIJT2 1
IC302 nsp I.C , FLASH U-COM(LQFP-100P) CVITMPM330FYFG_CU 1
┗IC302
943243102490S U-COM CD5005
(
TMPM330FYFG, TOSHIBA
)
CVIANAM1783
C
1*
IC304 90M-HC109330R AUDIO DAC (TSSOP-28 PACKAGE) HVICS4398CZ 1
Q100 00D9430058908 T.R , CHIP , SOT-23 HVTKTA1504SYRTK 1
Q101 00D2730464901 T.R , CHIP , SOT-23 HVTKTC3875SYRTK 1
Q300 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1
Q301 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1
Q302 00D2730464901 T.R , CHIP , SOT-23 HVTKTC3875SYRTK 1
RESISTOR GROUP
R1 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R2 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R3,4 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R6 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R7 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R9 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R10 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R11-16 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 6
R17 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R25-28 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
R20,21 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R34 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R36 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R37,38 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 2
R40 nsp RES, CHIP(1608/5%/270ohm) CRJ10DJ271T 1
R41 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R42,43 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R44,45 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R100 nsp RES, CHIP(1608/5%/91ohm) CRJ10DJ910T 1
R101,102 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R103-105 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 3
R106-108 nsp RES, CHIP(1608/5%/39ohm) CRJ10DJ390T 3
R109 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R110 nsp RES, CHIP(1608/5%/39ohm) CRJ10DJ390T 1
R111,112 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R113 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R114 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R115 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R116 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R118-120 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
R121 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R122,123 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R124,125 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R126 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R127 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R128 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R130 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R131,132 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R134 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R135,136 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R137-139 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R140 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R141,142 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R147 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R149 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R150-152 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 3
R155 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R157 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R158 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R159 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R160 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R162 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R166 nsp RES, CHIP(1608/5%/22ohm) CRJ10DJ220T 1
R167-171 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 5
R172 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R173 nsp RES, CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R174 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R180,181 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R182 nsp RES, CHIP(1608/5%/68ohm) CRJ10DJ680T 1
R183 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R184 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R185 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R187 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R214,215 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R300 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R301 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R302-308 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 7
R310 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R311 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R312,313 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 2
R314 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R315 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R316 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R317 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R318 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R319 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R320,321 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 2
