Marantz CR401 - Page 36

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
CD C266 ns
p
00MOA22605020 ELECT CAP. 22UF-M/50V,6*11 D040220087100
F
CD C267 ns
p
00MDD95101300 CER. CAP. COG100PF-J/50V-1608 D010101167160S
CD C268 ns
p
00MDD95101300 CER. CAP. COG100PF-J/50V-1608 D010101167160S
CD C269 ns
p
00MDK96102300 CER. CAP. X7R1000PF-K/50V-1608 D011102777160S
CD C270 ns
p
00MOA22605020 ELECT CAP. 22UF-M/50V,6*11 D040220087100
F
CD C271 ns
p
00MOA22605020 ELECT CAP. 22UF-M/50V,6*11 D040220087100
F
CD C272 ns
p
00MDK96102300 CER. CAP. X7R1000PF-K/50V-1608 D011102777160S
CD C273 ns
p
00MOA22605020 ELECT CAP. 22UF-M/50V,6*11 D040220087100
F
CD C274 ns
p
00MDK96102300 CER. CAP. X7R1000PF-K/50V-1608 D011102777160S
CD C275 ns
p
00MDK96102300 CER. CAP. X7R1000PF-K/50V-1608 D011102777160S
CD C276 ns
p
00MOA47601640 ELECT CAP. 47UF-M/16V,5*11-5RE.S
Y
D040470083080
F
CD C277 ns
p
00MDK96104300 CER. CAP. X7R0.1UF-K/50V-1608 D011104577160S
CD C278 ns
p
00MOA10701620 ELECT CAP. 100UF-M/16V,6.3*11 D040101083100
F
CD C279 ns
p
00MOA10701620 ELECT CAP. 100UF-M/16V,6.3*11 D040101083100
F
CD C280 ns
p
00MDK96102300 CER. CAP. X7R1000PF-K/50V-1608 D011102777160S
CD C281 ns
p
00MEA22601610 ELECT CAP. 22UF-M/16V,5*5-5RE S
Y
D040220083060
F
CD C282 ns
p
00MDK96473200 CER. CAP. X7R0.047UF-K/16V-1608 D011473773160S
CD C283 ns
p
00MOA22605020 ELECT CAP. 22UF-M/50V,6*11 D040220087100
F
CD C284 ns
p
00MDK96102300 CER. CAP. X7R1000PF-K/50V-1608 D011102777160S
CD C285 ns
p
00MDK96104300 CER. CAP. X7R0.1UF-K/50V-1608 D011104577160S
CD C286 ns
p
00MDD95101300 CER. CAP. COG100PF-J/50V-1608 D010101167160S
CD C287 ns
p
00MDD95220300 CER. CAP. COG22PF-J/50V-1608 D010220167160S
CD C288 ns
p
00MDD95220300 CER. CAP. COG22PF-J/50V-1608 D010220167160S
CD C289 ns
p
00MOA22405020 ELECT CAP. 0.22UF-M/50V,5*11 D040R22087100
F
CD C290 ns
p
00MOA22405020 ELECT CAP. 0.22UF-M/50V,5*11 D040R22087100
F
CD C291 ns
p
00MDK96104300 CER. CAP. X7R0.1UF-K/50V-1608 D011104577160S
CD C292 ns
p
00MDK96104300 CER. CAP. X7R0.1UF-K/50V-1608 D011104577160S
CD C293 ns
p
00MOA22605020 ELECT CAP. 22UF-M/50V,6*11 D040220087100
F
CD C294 ns
p
00MOA22605020 ELECT CAP. 22UF-M/50V,6*11 D040220087100
F
CD CN202 ns
p
ns
p
CONN. CORD 110MM/5P GIL-S-05=CKM2002H-0
5
L000111050120S
CD CP201 ns
p
ns
p
CONN. G1L-S-6P-S2T2-EF L101220060000S
CD CP203 ns
p
ns
p
CONN. 6232-16P DIP AN L130623201620S
CD CP205 ns
p
ns
p
CONN. G1L-S-6P-S2T2-EF L101220060000S
CD CP206 ns
p
ns
p
CONN. 5267-03A 3P L102526700300S
CD CP207 ns
p
ns
p
CONN. SCB 1119-00 19P S
T
L131111900010S
CD D201 ns
p
00D9630219709 DIODE 1N4148W SOD-323 K005041480020S
CD IC201 90M-HC107340R 90M-HC107340R IC CXA2581N-24P J030258100020S
CD IC202 90M-HC107400R 90M-HC107400R IC BA5979S/DIP32P J127597900020S
CD IC203 90M-HC107350R 90M-HC107350R IC CXD3068Q QFP80 J032306800010S
CD IC204 90M-HC107410R 90M-HC107410R IC BA6956AN SIP9 J127695600010S
CD IC205 90M-HC400040R 90M-HC400040R IC BA4558F-E2/SOP8P J121455800140S
CD IC206 90M-HC400040R 90M-HC400040R IC BA4558F-E2/SOP8P J121455800140S
CD IC207 90M-HC109580R 90M-HC109580R IC TMD2201A TQFP 80 J040220100010S
CD IC208 90M-HC109600R 90M-HC109600R IC IC42S16400 TSOP54 J001421640020S
CD IC209 90M-HC109590R 90M-HC109590R IC WM8761 24BIT 192KHZ SOIC14
P
J04287610001
0
CD IC210 90M-HS01CW20R 90M-HS01CW20R U-PRO MSM66Q573L-NTB TQFP100P J020665730030S
CD IC211 90M-HS01CW30R 90M-HS01CW30R IC M29W800DB 3163005 8M
(
BLANK
)
J005298000060S
CD L201 90M-FN000270R 90M-FN000270R EMI FILTER MB-160808-0120H SMD160
8
D340160800060S
CD L202 00D963012650
4
00D963012650
4
EMI FILTER BFS 3550R2F 3.5*5.0 R.REEL
(
5MM
)
7610035500030S
CD L203 ns
p
ns
p
COIL 10UH-Q40/24M-R2.5-52RE 02TB D330100700520S
CD L204 90M-FN000270R 90M-FN000270R EMI FILTER MB-160808-0120H SMD1608 TYP
E
D340160800060S
CD L205 90M-FN000270R 90M-FN000270R EMI FILTER MB-160808-0120H SMD1608 TYP
E
D340160800060S
CD L206 00D963012650
4
00D963012650
4
EMI FILTER BFS 3550R2F 3.5*5.0 R.REEL
(
5MM
)
7610035500030S
CD L207 00D963012650
4
00D963012650
4
EMI FILTER BFS 3550R2F 3.5*5.0 R.REEL
(
5MM
)
7610035500030S
CD L208 90M-FN000270R 90M-FN000270R EMI FILTER MB-160808-0120H SMD1608 TYP
E
D340160800060S
CD L209 90M-FN000270R 90M-FN000270R EMI FILTER MB-160808-0120H SMD1608 TYP
E
D340160800060S
CD L210 00D963012650
4
00D963012650
4
EMI FILTER BFS 3550R2F 3.5*5.0 R.REEL
(
5MM
)
7610035500030S
CD L211 90M-FN000270R 90M-FN000270R EMI FILTER MB-160808-0120H SMD1608 TYP
E
D340160800060S
CD Q201 90M-BA001250R 90M-BA001250R TRS. KTA1273Y,1W/TO92
L
J5001273Y0050S
CD Q205 90M-BA001170R 90M-BA001170R TRS. KRA107S
(
PH
)
/SOT-23 J5200107S0050S
CD Q206 00D9630226909 00D9630226909 TRS. KRC114S
(
NP
)
0.2W/SOT-23 J522011400210S
CD Q207 00D9630226909 00D9630226909 TRS. KRC114S
(
NP
)
0.2W/SOT-23 J522011400210S
CD Q208 00D9630226909 00D9630226909 TRS. KRC114S
(
NP
)
0.2W/SOT-23 J522011400210S
CD Q211 90M-HT300870R 90M-HT300870R TRS. KTC2875B
(
MB
)
0.15W SOT23
(
RTK
)
J5222875B0010S
CD Q212 90M-HT300870R 90M-HT300870R TRS. KTC2875B
(
MB
)
0.15W SOT23
(
RTK
)
J5222875B0010S
CD Q213 90M-BA001540R 90M-BA001540R TRS. KRA101S R1,R2=4.7K 0.2W/SOT-2
3
J520010100010S
CD Q214 90M-BA001160R 90M-BA001160R TRS. TR CHIP KRC107S SOT23 J5020107S0050S
46
