Marantz CR401 - Page 42

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
FRONT VR702 90M-RB000080R 90M-RB000080R VAR. RES. RK14K1270301-10KB*2 C454121300040S
FRONT VR703 90M-SR000300R 90M-SR000300R ROTARY SW EC12B24S2036ZZZ 24PULSE/360'2
4
G121122420360
FRONT ZD701 00MHD30511000 00MHD30511000 ZENER DIODE MTZJ5.1B-0.5W/5MA-52MM K06005R144520S
GUIDE PWB
GUIDE CP506 90M-YJ002950R 90M-YJ002950R CONN. TUC-P12X-B1 BD-TO-BD 12P L101100031210S
GUIDE CP302 90M-YJ002960R 90M-YJ002960R CONN. TUC-P11X-B1 BD-TO-BD 11P L101100031110S
MAIN PWB
MAIN BEAD101 90M-FC900420R 90M-FC900420R EMI FILTER 3580-52RE-AX 7610010030000S
MAIN C101 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C102 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C103 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C104 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C105 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C106 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C107 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C108 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C109 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C110 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C111 ns
p
00MOA10602520 ELECT CAP. 10UF-M/25V,5*11-5RE S
Y
D040100084050
F
MAIN C112 ns
p
00MDK96331300 CER. CAP. COG330PF-J/50V-1608 D010331167160S
MAIN C113 ns
p
00MOA10602520 ELECT CAP. 10UF-M/25V,5*11-5RE S
Y
D040100084050
F
MAIN C114 ns
p
00MOA10602520 ELECT CAP. 10UF-M/25V,5*11-5RE S
Y
D040100084050
F
MAIN C115 ns
p
00MDK96331300 CER. CAP. COG330PF-J/50V-1608 D010331167160S
MAIN C116 ns
p
00MOA10602520 ELECT CAP. 10UF-M/25V,5*11-5RE S
Y
D040100084050
F
MAIN C117 ns
p
00MOA22505020 ELECT CAP. 2.2UF-M/50V,5*11-5RE D0402R2087100
F
MAIN C118 ns
p
00MOA22505020 ELECT CAP. 2.2UF-M/50V,5*11-5RE D0402R2087100
F
MAIN C119 ns
p
00MOA22505020 ELECT CAP. 2.2UF-M/50V,5*11-5RE D0402R2087100
F
MAIN C120 ns
p
00MOA22505020 ELECT CAP. 2.2UF-M/50V,5*11-5RE D0402R2087100
F
MAIN C121 ns
p
00MOA22505020 ELECT CAP. 2.2UF-M/50V,5*11-5RE D0402R2087100
F
MAIN C122 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C123 ns
p
00MOA22700620 ELECT CAP. 220UF-M/6.3V,6.3*11-5RE-SMS S
Y
D040221081050
F
MAIN C124 ns
p
00MDK96331300 CER. CAP. COG330PF-J/50V-1608 D010331167160S
MAIN C125 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C126 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C127 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C128 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C129 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C130 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C131 ns
p
00MOA22505020 ELECT CAP. 2.2UF-M/50V,5*11-5RE D0402R2087100
F
MAIN C132 ns
p
00MDK96331300 CER. CAP. COG330PF-J/50V-1608 D010331167160S
MAIN C133 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C134 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C135 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C136 ns
p
00MDD95300300 CER. CAP. COG30PF-J/50V-1608 D010300167160S
MAIN C137 ns
p
00MDD95300300 CER. CAP. COG30PF-J/50V-1608 D010300167160S
MAIN C138 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C139 ns
p
00MOA22505020 ELECT CAP. 2.2UF-M/50V,5*11-5RE D0402R2087100
F
MAIN C140 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C141 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C142 ns
p
00MDK96221300 CER. CAP. COG220PF-J/50V-1608 D010221167160S
MAIN C143 ns
p
00MDK96104300 CER. CAP. X7R0.1UF-K/50V-1608 D011104577160S
MAIN C144 ns
p
00MDK96103300 CER. CAP. X7R0.01UF-K/50V-1608 D011103777160S
MAIN C191 ns
p
00MOA22700620 ELECT CAP. 220UF-M/6.3V,6.3*11-5RE-SMS S
Y
D040221081050
F
MAIN C192 90M-EX000090R 90M-EX000090R ELECT CAP. H0.047F-70UA/5.5V-5RE D090473904010S
MAIN CN101 90M-YJ002980R 90M-YJ002980R CONN. TMC-D12X-A1 BLK 12P S
T
L102120000040S
MAIN CN102 90M-YJ002980R 90M-YJ002980R CONN. TMC-D12X-A1 BLK 12P S
T
L102120000040S
MAIN CN107 ns
p
ns
p
CONN. SCB 1119-00 19P S
T
L131111900010S
MAIN CP104 90M-YP100370R 90M-YP100370R CONN. TUC-P11P-B1 BD-TO-BD 11P L101100041110S
MAIN CP105 90M-YP100360R 90M-YP100360R CONN. TUC-P17P-B1 BD-TO-BD 17P L101100041710S
MAIN CP106 ns
p
ns
p
CONN. 53014-0910 9P L101530140910S
MAIN CP107 90M-YP100350R 90M-YP100350R CONN. TUC-P04P-B1 BD-TO-BD 4P L101100040410S
MAIN CP108 ns
p
ns
p
CONN. SCB 1113-00 13P S
T
L131111300010S
MAIN CP110 ns
p
ns
p
CONN. G1L-S-7P-S2T2-EF L101220070000S
MAIN D101 ns
p
00D9630219709 DIODE 1N4148W SOD-323 K005041480020S
MAIN D102 ns
p
00D9630219709 DIODE 1N4148W SOD-323 K005041480020S
MAIN D103 ns
p
00D9630219709 DIODE 1N4148W SOD-323 K005041480020S
MAIN D104 ns
p
00D9630219709 DIODE 1N4148W SOD-323 K005041480020S
