Marantz DV9600 - Page 159

193
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS.•NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
1 nsp nsp CHASSIS MAIN CHASSIS ASS
Y
9KC 1A01 7
2 90M13AK160210 90M13AK160210 BRAKET CLAMPER BRACKE
T
9KA 7P08 5
3 nsp nsp BRAKET GUIDE CLAMP BRACKE
T
4 90M-MM001290
R
90M-MM001290
R
MOTOR LOADING MOTOR ASS
Y
9KC 2A00 3
5 90M13AK058230 90M13AK058230 GEAR LOADING GEAR 9KC 2G02 9
6 90M13AK058210 90M13AK058210 GEAR LOADING GEAR 2ND 9KB 9G03 0
7 90M13AK058220 90M13AK058220 GEAR LOADING GEAR 3RD 9KB 9G03 1
8 90M13AK105210 90M13AK105210 CHASSIS SUB CHASSIS-
L
9KA 2G41 7
9 90M13AK105220 90M13AK105220 CHASSIS SUB CHASSIS-
R
9KA 2G41 8
10 90M13AK163210 90M13AK163210 TRAY TRAY-D4 9KA 2G778
11 90M13AK054210 90M13AK054210 CAM SLIDE-CAM 9KC 1G00 3
12 90M13AK002210 90M13AK002210 ARM TRAVERSE ARM 9KC 1G00 4
14 90M13AK005210 90M13AK005210 CLAMPER CLAMPER H 9KA 7G20 2
15 90M13AK005220 90M13AK005220 CLAMPER CLAMPER
L
9KA 7G20 3
16 90M13AK264210 90M13AK264210 BELT LOADING BELT 9KB 9G01 5
17 nsp nsp PCB ASSY SWITCH P.W.B. 9KC 1P01 4
18 nsp nsp CORD 5P PH WIRE 9KC 2G04 3
19 90M-SP001260
R
90M-SP001260
R
SWITCH SWITCH ESE22MH21 9KS 01W2 04
20 90M-SP001270
R
90M-SP001270
R
SWITCH SWITCH ESE22MH23 9KS 01W2 05
21 90M13AK012210 90M13AK012210 WASHER POLY.SLIT WASHER 2.6X6X0.25
C
9KP 26C6 25
22 nsp nsp CLAMPER WIRE CLAMPER 445 8004 00
7
23 nsp nsp SCREW PRECISION SCREW 1.7X2.2 TYPE
3
9KS 17N0 22
23 nsp nsp SCREW PRECISION SCREW 1.7X2.2 TYPE
3
23 nsp nsp SCREW PRECISION SCREW 1.7X2.2 TYPE
3
24 nsp nsp SCREW SCREW 2.6X6 CBTS(B)-
Z
9KB 26BK 06
25 nsp nsp SCREW PRECISION SCREW 2X3(S) TYPE
3
9KS 20TK 33
26 nsp nsp SCREW SCREW 2X6 CBTS(P)-
Z
9KB 20PK 06
27A 90M13AK304210 90M13AK304210 MECHANISM TRAVERSE MECHA (FEED) ASSY 9KC 2A06 3
A
27 nsp nsp CHASSIS PU CHASSIS ASS
Y
28 nsp nsp HOLDER SHAFT HOLDER
L
29 nsp nsp HOLDER SHAFT HOLDER R
30 nsp nsp BRAKET SHAFT TILT BASE
31 nsp nsp RETAINER SHAFT TILT PLATE
32 nsp nsp SPRING TILT SPRING
33 nsp nsp SHAFT MAIN SHAFT
34 nsp nsp SHAFT SUB SHAFT
35 nsp nsp GEAR PU RACK GEAR
36 nsp nsp GEAR FEED GEAR 2ND ASS
Y
37 nsp nsp MECHANISM PICK UP HOP-1200
R
38 nsp nsp SPRING PU SPRING
39 nsp nsp SPRING SHAFT SPRING
40 nsp nsp SPRING RACK GEAR SPRING
41 nsp nsp MOTOR FEED MOTOR ASSY
42 nsp nsp MOTOR T/T MOTOR ASSY
43 nsp nsp SCREW SCREW 2.6X6 CBTS(S)-
Z
44 nsp nsp SCREW SCREW 2.6X4 CBTS(S)-
Z
46 nsp nsp SCREW SCREW 2.6X15 CFTS(S)-
Z
47 nsp nsp SCREW SCREW 3X4 BSS
48 nsp nsp SCREW SCREW 3X8 BSS (A)
49 90M13AK130210 90M13AK130210 DAMPER DAMPER-SI25-L
B
9KA 2G643
50 nsp nsp WASHER POLY.SLIT WASHER 2.1X4X0.25
C
51 nsp nsp SCREW SPECIAL SCREW (FRONT)
52 nsp nsp SCREW SPECIAL SCREW (REAR)
53 nsp nsp GEAR FEED GEAR 3RD
54 90M13AK116210 90M13AK116210 LEAF SPRING TRAY-SPRING-VXF 9KB 7P02 4
60 90M13AK104210 90M13AK104210 RETAINER PLATE-RE-2HPC 9KC 2P03 1
61 90M13AK104220 90M13AK104220 RETAINER WF-PLATE-RE-2HPC 9KC 2P03 2
62 nsp nsp SCREW PRECISION SCREW 2X4(P) TYPE1 9KS 20P1 04
63 nsp nsp SCREW PRECISION SCREW 1.7X5 TYPE
3
64 nsp nsp CUSHION RUBBER CUSHION 9KC 1G04 2
66 nsp 90M-YU001350
R
FPC FFC-0.5-24 L=80 9KA 2P70 6
68 nsp nsp TAPE TAPE W10X45 (NITTO NO.156)
70 nsp nsp CUSHION CUSHION L 6X3Xt
4
9KC 2G07 6
71 nsp nsp CUSHION CUSHION R 6X3Xt2 9KC 2G07 7
