14. MICROPROCESSOR AND IC DATA
[PM01] QU01: H8S/2238R
Pin PORT Signal name I/O Contents of control
1 PE5/D5 V_PSW O Power supply control for VIDEO. L
2 PE6/D6 P/XI O Prograssive=H
3 PE7/D7 N.C. I
4 PD0/D8 DB4 O LCD DRIVER DATA 4
5 PD1/D9 DB5 O LCD DRIVER DATA 5
6 PD2/D10 DB6 O LCD DRIVER DATA 6
7 PD3/D11 DB7 O LCD DRIVER DATA 7
8 PD4/D12 E O Write enable for LCD DRIVER
9 PD5/D13 R/W O Read/Write for LCD DRIVER
10 PD6/D14 RS O Instruction for LCD DRIVER, Select data
11 PD7/D15 N.C. I
12 CVCC
13 PC0/A0 N.C. I
14 VSS
15 PC1/A1 STB_CONT O STB=L, POWER=H L
16 PC2/A2 STB_LED O LED for standby H
17 PC3/A3 FL_OFF_LED O LED for FL OFF H
18 PC4/A4 DHD I Head Phone detection port, Head Phone=L L
19 PC5/A5 BYPASS O A.DSP bypass signal, Bypass=L L
20 PC6/A6 N.C. I
21 PC7/A7 N.C. I
22 PB0/A8/TIOCA3 VRST_1 O Reset for CD0040AF L
23 PB1/A9/TIOCB3 VRST_2 O Reset for ADV7314/7310 L
24 PB2/A10/TIOCC3 VRST_3 O Reset for PD0280B (Scaler) L
25 PB3/A11/TIOCD3 VRST_4 O Reset for SiI9290 (HDMI) L
26 PB4/A12/TIOCA4 N.C. I
27 PB5/A13/TIOCB4 N.C. I
28 PB6/A14/TIOCA5 MC_RST O Reset for B/E L
29 PB7/A15/TIOCB5 B/EON I STB mode input port for B/E
30 PA0/A16 N.C. I
31 PA1/A17/TxD2 DATAO_OP O Data output port for B/E
32 PA2/A18/RxD2 DATAI_OP I Data input port for B/E
33 PA3/A19/SCK2 CLK_OP O Clock input port for B/E
34 P10/TIOCA0/DACK0/A20 IR_IN I Input capture
35 P11/TIOCB0/DACK1/A21 N.C. I
36 P12/TIOCC0/TCLKA/A22 N.C. I
37 P13/TIOCD0/TCLKB/A23 N.C. I
38 P14/TIOCA1/IRQ0 CS_OP I External interruption (Chip selection input port for B/E)
39 P15/TIOCB1/TCLKC /DFRES I Circumference IC.)
40 P16/TIOCA2/IRQ1 DSPREQ1 I Interruption REQ1 for ADSP
41 P17/TIOCB2/TCLKD N.C. I
42 AVSS GND
43 P97/DA1 N.C. I
44 P96/DA0 N.C. I
45 P47/AN7 BIT2 I Version distinction 3
46 P46/AN6 BIT1 I Version distinction 2
47 P45/AN5 BIT0 I Version distinction 1
48 P44/AN4 SELECT I Model distinction
49 P43/AN3 KEY4 I KEY_4 input
50 P42/AN2 KEY3 I KEY_3 input
51 P41/AN1 KEY2 I KEY_2 input
52 P40/AN0 KEY1 I KEY_1 input
53 Vref
54 AVCC
55 MD0
56 MD1
57 OSC2
58 OSC1
59 RES CPU_RST CPU reset signal
L:DV8500 H:OEM
[PM01] QU01: H8S/2238R
Pin PORT Signal name I/O Contents of control
60 NMI
61 STBY
62 VCC Power supply
63 XTAL
64 VSS GND
65 EXTAL
66 "FEW"
67 MD2
68 PF7 VFD_CLK O Clock output port for LC75712. Software serial
69 PF6 VFD_CE O Chip enable output port for LC75712.
70 PF5/RD VFD_SDA O Data output port for LC75712. Software serial
71 PF4/HWR VFD_RES O Reset for LC75712.
72 PF3/LWR/ADTRG/IRQ3 KEY4 I External interruption (POWER/STANDBY SW detection)
73 PF2/WAIT N.C. I
74 PF1/BACK/BUZZ CTS I CTS input of RS232C
75 PF0/BREQ/IRQ2 RTS O RTS input of RS232C
76 P30/TxD0 RS_TXD/TXD2 O RS232C output
77 P31/RxD0 RS_RXD/RXD2 I RS232C input
78 P32/SCK0/SDA1/IRQ4 SDA1 I/O EEPROM/ADV7310/ADV7314
79 P33/TxD1/SCL1 SCL1 O EEPROM/ADV7310/ADV7314
80 P34/RxD1/SDA0 SDA2 I/O HDMI
81 P35/SCK1/SCL0/IRQ5 SDA2 O HDMI
82 P36 SCS O Chip selection port for A.DSP.
83 P77/TxD3 DSPDOUT O Serial data output port for A.DSP.
84 P76/RxD3 DSPDIN I Serial data input port for A.DSP.
85 P75/TMO3/SCK3 DSPCLK O Clock output port for A.DSP.
86 P74/TMO2/MRES FCS O Chip selection port for A.DSP. L
87 P73/TMO1/TEND1/CS7 HINBSY I
88 P72/TMO0/TEND0/CS6 RSTDSP O Reset for A.DSP. L
89 P71/TMRI23/TMCI23/DREQ1/CS
5 FILT_SEL I Audio DAC detection
90 P70/TMRI01/TMCI01/DREQ0/CS4 DIR_DSD I Audio DAC detection
91 PG0/IRQ6 DSPREQ2 I Interruption REQ2 for ADSP
92 PG1/CS3/IRQ7 HDMI_INT I Interruption signal for SiI9190 L
93 PG2/CS2 CCLK O Clock for CS4398 DAC Software serial
94 PG3/CS1 CDOUT O Data output port for CS4398 DAC Software serial
95 PG4/CS0 CDIN I Data input for CS4398 DAC Software serial
96 PE0/D0 CS1 O Chip selection port for CS4398 DAC L
97 PE1/D1 CS2 O Chip selection port for CS4399 DAC L
98 PE2/D2 RST O Reset for CS4398 DAC L
99 PE3/D3 DAC_MUTE1 O Mute for audio L
100 PE4/D4 DAC_MUTE2 O Mute for audio L
