Marantz DV9600 - Page 167

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
PA01 CS06
/
L1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS06
/
N1S 00MOF55221560 00MOF55221560 FILM CAP. DAMG 220PF 630
V
PA01 CS06
/
S1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS06
/
U1B ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS08 F B ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS08 F N ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS08
/
K1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS08
/
L1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS08
/
N1S 00MOF55221560 00MOF55221560 FILM CAP. DAMG 220PF 630
V
PA01 CS08
/
S1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS08
/
U1B ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS10 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
PA01 CS11 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
PA01 CS33 00MOF55101560 00MOF55101560 FILM CAP. DAMG 100PF 630
V
PA01 CS34 00MOF55102570 00MOF55102570 FILM CAP. DTG 1000PF 100
V
PA01 CS35 00MOF55102570 00MOF55102570 FILM CAP. DTG 1000PF 100
V
PA01 CS36 F B ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS36 F N ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS36
/
K1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS36
/
L1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS36
/
N1S 00MOF55221560 00MOF55221560 FILM CAP. DAMG 220PF 630
V
PA01 CS36
/
S1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS36
/
U1B ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS38 F B ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS38 F N ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS38
/
K1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS38
/
L1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS38
/
N1S 00MOF55221560 00MOF55221560 FILM CAP. DAMG 220PF 630
V
PA01 CS38
/
S1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS38
/
U1B ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
PA01 CS40 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
PA01 CS41 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
PA01 DA01 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DA21 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DA22 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DA51 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DC21 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DC51 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DH01 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH02 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PA01 DH11 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH12 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PA01 DH21 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH22 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PA01 DH31 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH32 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PA01 DH41 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH42 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PA01 DH51 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH52 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PA01 DS21 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DS51 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 LA01 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PA01 QA01 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V RAN
K
PA01 QA02 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V RAN
K
PA01 QA04 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QA06
/
N1S 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
PA01 QA07 00MBA20035210 00MBA20035210 TRS. DTC114EU
PA01 QA08 00MBA20035210 00MBA20035210 TRS. DTC114EU
PA01 QA09 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 QA11 00MBA20035210 00MBA20035210 TRS. DTC114EU
PA01 QA12 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 QA13 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QA31 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V RAN
K
PA01 QA32 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V RAN
K
PA01 QA34 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QA36
/
N1S 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
201
