NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
PA01 RS35 00MNI05222110 00MNI05222110 CHIP RES. 2.2K OHM +-5% 1/10
W
PA01 RS36 00MNI05222110 00MNI05222110 CHIP RES. 2.2K OHM +-5% 1/10
W
PA01 RS37 00MNI05123110 00MNI05123110 CHIP RES. 12K OHM +-5% 1/10
W
PA01 RS38 00MNI05153110 00MNI05153110 CHIP RES. 15K OHM +-5% 1/10
W
PA01 RS39 00MNI05123110 00MNI05123110 CHIP RES. 12K OHM +-5% 1/10
W
PA01 RS40 00MNI05153110 00MNI05153110 CHIP RES. 15K OHM +-5% 1/10
W
PA01 RS43 00MNI05473110 00MNI05473110 CHIP RES. 47K OHM +-5% 1/10
W
PA01 RS44 00MNI05680110 00MNI05680110 CHIP RES. 68 OHM +-5% 1/10
W
PA01 RS45 00MNI05680110 00MNI05680110 CHIP RES. 68 OHM +-5% 1/10
W
PA01 RS46 00MNI05104110 00MNI05104110 CHIP RES. 100K OHM +-5% 1/10
W
PA01 RS47 ns
p
00MNN05224610 CHIP RES. 220K OHM +-5% 1/16
W
PA01 RS48 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +-5% 1/16
W
PA01 RS49 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +-5% 1/16
W
PA01 RS50 00MNI05680110 00MNI05680110 CHIP RES. 68 OHM +-5% 1/10
W
PA01 RS55 ns
p
00MNN05102610 CHIP RES. 1K OHM +-5% 1/16
W
PA01 RS57 ns
p
00MNN05332610 CHIP RES. 3.3K OHM +-5% 1/16
W
PA01 RS58 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16
W
FLASHER PWB
(
00MWA25AK601-
)
PB01 CB02 ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PB01 DB01 00MHI20002210 00MHI20002210 GAS LED GL-350 SIR-34ST3F
PB01 JB01 00MYJ0100500
0
00MYJ0100500
0
JACK LGY6501-0900FC
PB01 QB01 00MHW10005210 00MHW10005210 PHOTO UNIT RPM6936 IR RECEIVER 36KH
Z
PB01 QB02 00MBA10001000 00MBA10001000 TRS. DTA114ES/UN4111 10K,10
K
PB01 QB03 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
PB01 QB04 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
PB01 QB05 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
HDMI PWB
(
00MWI25AK501-
)
PD01 CT01 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT02 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT03 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT04 00MDK06102200 00MDK06102200 CER. CAP. 1000 PF +-10% B 25V GRM3
6
PD01 CT05 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF 10V
PD01 CT06 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT07 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT08 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT09 00MDK06102200 00MDK06102200 CER. CAP. 1000 PF +-10% B 25V GRM3
6
PD01 CT10 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF 10V
PD01 CT11 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT12 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT13 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT14 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT15 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT16 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT17 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT18 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT19 00MEY10601670 00MEY10601670 TANTL.CAP CHIP MSVB21C 10UF 16
V
PD01 CT20 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT21 00MEY10601670 00MEY10601670 TANTL.CAP CHIP MSVB21C 10UF 16
V
PD01 CT22 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT23 00MEY10601670 00MEY10601670 TANTL.CAP CHIP MSVB21C 10UF 16
V
PD01 CT24 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT25 00MEY10701670 00MEY10701670 TANTL.CAP CHIP 100UF 16V
PD01 CT26 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT27 00MEY10601670 00MEY10601670 TANTL.CAP CHIP MSVB21C 10UF 16
V
PD01 CT28 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT29 00MEY10701670 00MEY10701670 TANTL.CAP CHIP 100UF 16V
PD01 CT30 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT31 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT32 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT33 00MDK06102200 00MDK06102200 CER. CAP. 1000 PF +-10% B 25V GRM3
6
PD01 CT36 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT37 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT51 00MDD05101200 00MDD05101200 CER. CAP. 100 PF +-5% CH 25
V
PD01 CT52 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
PD01 CT54 ns
p
00MDK96105200 CER. CAP. 1UF B 6.3V
PD01 CT57 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
(
47UF 16V
)
PD01 CT58 00MDK06104200 00MDK06104200 CER. CAP. 0.1 UF +-10% B 10
V
206
