Marantz DV9600 - Page 177

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
PF01 CF80 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PF01 CF81 ns
p
00MDD95101300 CER. CAP. 100 PF +-5% CG 50V GR39
PF01 DF31 00MHI10062320 00MHI10062320 L.E.D. LT3D8B RED 3O
PF01 LF01 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 LF02 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 LF03 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 LF71 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 LF72 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 QF21 00MBA10026210 00MBA10026210 TRS. DTA114EU
PF01 QF31 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF01 QF36 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF01 QF71 00MHC10416030 00MHC10416030 IC FL DRIVER LC75712NE
PF01 QF80 00MHC007805K0 00MHC007805K0 IC TC74VHCT125AFT OUAD BUS BUFFER
PF01 RF01 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF02 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF03 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF04 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF05 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF06 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF07 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF08 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF09 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF10 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF11 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
PF01 RF12 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PF01 RF21 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16
W
PF01 RF23 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16
W
PF01 RF31 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16
W
PF01 RF32 ns
p
00MNN05272610 CHIP RES. 2.7K OHM +-5% 1/16
W
PF01 RF37 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16
W
PF01 RF38 ns
p
00MNN05332610 CHIP RES. 3.3K OHM +-5% 1/16
W
PF01 RF42 ns
p
00MNN05562610 CHIP RES. 5.6K OHM +-5% 1/16
W
PF01 RF43 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16
W
PF01 RF45 ns
p
00MNN05562610 CHIP RES. 5.6K OHM +-5% 1/16
W
PF01 RF46 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16
W
PF01 RF48 ns
p
00MNN05562610 CHIP RES. 5.6K OHM +-5% 1/16
W
PF01 RF71 ns
p
00MNN05153610 CHIP RES. 15K OHM +-5% 1/16
W
PF01 RF72 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16
W
PF01 RF80 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16
W
PF01 SF01 00MSP01012030 00MSP01012030 PUSH SW SKHVBF 260GF RED
PF01 SF02 00MSP01012030 00MSP01012030 PUSH SW SKHVBF 260GF RED
PF01 SF03 00MSP01012030 00MSP01012030 PUSH SW SKHVBF 260GF RED
PF01 SF04 00MSP01012030 00MSP01012030 PUSH SW SKHVBF 260GF RED
PF01 SF05 00MSP01012030 00MSP01012030 PUSH SW SKHVBF 260GF RED
PF01 SF06 00MSP01012030 00MSP01012030 PUSH SW SKHVBF 260GF RED
PF01 SF07 00MSP01012030 00MSP01012030 PUSH SW SKHVBF 260GF RED
PF01 SF08 00MSP01012030 00MSP01012030 PUSH SW SKHVBF 260GF RED
PF01 VF01 00MHQ31303920 00MHQ31303920 DISPLAY CH2163C
PF01 ZF21 00MHW10004210 00MHW10004210 PHOTO UNIT RPM6936-V4
(
IR SENSOR
)
HP PWB
(
00MWG21AK403-
)
PH01 C959 ns
p
00MOA22701620 ELECT. CAP. 220 UF M 16V RA-2
PH01 C960 ns
p
00MOA22701620 ELECT. CAP. 220 UF M 16V RA-2
PH01 C961 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C962 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C963 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C964 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C965 00MDF15332350 00MDF15332350 FILM CAP. 0.0033UF,J,M,50
V
PH01 C966 00MDF15332350 00MDF15332350 FILM CAP. 0.0033UF,J,M,50
V
PH01 C967 00MDF15222350 00MDF15222350 FILM CAP. 0.0022UF,J,M,50
V
PH01 C968 00MDF15222350 00MDF15222350 FILM CAP. 0.0022UF,J,M,50
V
PH01 C969 ns
p
00MDD95101300 CER. CAP. 100 PF +-5% CG 50V GR39
PH01 C970 ns
p
00MDD95101300 CER. CAP. 100 PF +-5% CG 50V GR39
PH01 C971 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C972 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C973 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10% B 50V GR3
6
PH01 C974 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10% B 50V GR3
6
PH01 J952 00MYJ0100424
0
00MYJ0100424
0
JACK HLJ2307-01-3160
