NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
PM01 CU04 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PM01 CU05 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PM01 CU06 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PM01 CU07 ns
p
00MDD95101300 CER. CAP. 100 PF +-5% CG 50V GR39
PM01 CU23 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PM01 CU91 00MEY47601620 00MEY47601620 ELECT CAP. 47UF 16V
PM01 CU92 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PM01 CU93 00MEY10700620 00MEY10700620 ELECT CAP. 100UF 6.3V
PM01 CU94 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PM01 CU95 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PM01 D101 00MHZ21303210 00MHZ21303210 CHIP DIODE DIOD 1SS355
PM01 D102 00MHZ21303210 00MHZ21303210 CHIP DIODE DIOD 1SS355
PM01 D103 00MHZ21303210 00MHZ21303210 CHIP DIODE DIOD 1SS355
PM01 D104 00MHZ21303210 00MHZ21303210 CHIP DIODE DIOD 1SS355
PM01 D105 00MHZ21303210 00MHZ21303210 CHIP DIODE DIOD 1SS355
PM01 D108 00MHZ21303210 00MHZ21303210 CHIP DIODE DIOD 1SS355
PM01 D501 00MHZ20002020 00MHZ20002020 CHIP DIODE MA151WA-
(
TX
)
PM01 D502 00MHZ20002020 00MHZ20002020 CHIP DIODE MA151WA-
(
TX
)
PM01 DU01 00MHZ20038050 00MHZ20038050 CHIP DIODE 1SS300
PM01 DU02 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PM01 DU03 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PM01 DU04 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PM01 J503 00MYJ0706109
0
00MYJ0706109
0
JACK 52207-1590 1MM FFC 15
P
PM01 J506 00MYJ0701668
0
00MYJ0701668
0
JACK 24FLZ-SM1-TB
PM01 J702 00MYJ0702116
0
00MYJ0702116
0
JACK 14FLT-SM2-TB
(
LF
)(
SN
)
PM01 J703 00MYJ0702117
0
00MYJ0702117
0
JACK 16FLT-SM2-TB
(
LF
)(
SN
)
PM01 JK01 00MYJ0706019
0
00MYJ0706019
0
JACK 40FLT-SM1-TB
PM01 L101 00MFM1222302
0
00MFM1222302
0
EMI FILTER DSS306-55F223Z16 DC MAX:16
V
PM01 L102 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L103 00MFC90020220 00MFC90020220 FERRITE CORE BLM18AG121SN1D
PM01 L104 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L105 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L109 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L110 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L111 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L112 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L114 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L115 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L116 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L117 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L118 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L119 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L122 ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PM01 L301 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L302 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L401 00MFC90020150 00MFC90020150 FERRITE CORE BLM11P300S
PM01 L402 00MFC90020150 00MFC90020150 FERRITE CORE BLM11P300S
PM01 L403 00MFC90020150 00MFC90020150 FERRITE CORE BLM11P300S
PM01 L404 00MFC90020150 00MFC90020150 FERRITE CORE BLM11P300S
PM01 L405 00MFC90020150 00MFC90020150 FERRITE CORE BLM11P300S
PM01 L406 00MFC90020150 00MFC90020150 FERRITE CORE BLM11P300S
PM01 L407 00MFC90020150 00MFC90020150 FERRITE CORE BLM11P300S
PM01 L501 ns
p
00MNN05331610 CHIP RES. 330 OHM +-5% 1/16
W
PM01 L502 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L503 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L702 00MFC90020150 00MFC90020150 FERRITE CORE BLM11P300S
PM01 L951 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L952 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L953 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L954 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L955 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 L956 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PM01 LK01 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK02 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK03 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK04 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK05 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
