Marantz DV9600 - Page 191

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
PM01 Q307 00MHC005805K0 00MHC005805K0 IC TC74VHC157FT TAPING
PM01 Q308 00MHC700801P0 00MHC700801P0 IC HD74LVC08
PM01 Q401 00MHC10081250 00MHC10081250 IC CXD2753R DSD DSP
PM01 Q402 00MHC10156990 00MHC10156990 IC EM636165TS-7
PM01 Q403 00MHC10209990 00MHC10209990 IC AD8062-REEL7
PM01 Q404 00MHC12249990 00MHC12249990 IC EPM3128ATC100-10N FOR DVD
PM01 Q405 00MHC000137K0 00MHC000137K0 IC SN74LV04APWR
PM01 Q501 00D2623219001 00D2623219001 IC CXD1881AR/BR +C
PM01 Q502 00MHC10084250 00MHC10084250 IC CXD1885Q
PM01 Q503 00D2623409002 00D2623409002 IC MSM51V18165F-50TSK-
7
PM01 Q505 00MHC10178020 00MHC10178020 IC AN8471SA-E1
PM01 Q507 00MHC700805S0 00MHC700805S0 IC TC7S08F TOSHIBA TAPING
PM01 Q508 00MHC10018110 00MHC10018110 IC FAN8042
PM01 Q510 00MHX211322A0 00MHX211322A0 CHIP TRS. 2SB1132Q,R
PM01 Q511 00MHX211322A0 00MHX211322A0 CHIP TRS. 2SB1132Q,R
PM01 Q512 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PM01 Q701 00MHC006105K0 00MHC006105K0 IC TC74VHC541F
T
PM01 Q703 00MHC10055990 00MHC10055990 IC EPM3064ATC44-10N
PM01 Q705 00MHC10010210 00MHC10010210 IC BU2370FV
PM01 Q706 00MHC10084090 00MHC10084090 IC NJM2107F JRC
PM01 Q707 00MHC006105K0 00MHC006105K0 IC TC74VHC541F
T
PM01 Q710 00MHC10224210 00MHC10224210 IC BD4742G RESET IC 4.2
V
PM01 Q950 00MHC10025880 00MHC10025880 IC CS4392-KZZ LEAD FREE
PM01 Q955 00MHC10440050 00MHC10440050 IC TC7SH08FU
PM01 QK01 00MHC10022660 00MHC10022660 IC CM0039AF IP-CONVERTER
PM01 QK03 00MHC10001910 00MHC10001910 IC K4S643232E-TC60/K4S643232H-TC6
0
PM01 QK05 00MHC006105K0 00MHC006105K0 IC TC74VHC541F
T
PM01 QK06 00MHC006105K0 00MHC006105K0 IC TC74VHC541F
T
PM01 QK07 00MHC10384050 00MHC10384050 IC TC7S66FU
PM01 QK08 00MHC10384050 00MHC10384050 IC TC7S66FU
PM01 QK09 00MHC10440050 00MHC10440050 IC TC7SH08FU
PM01 QK10 00MHC006105K0 00MHC006105K0 IC TC74VHC541F
T
PM01 QK11 00MHC006105K0 00MHC006105K0 IC TC74VHC541F
T
PM01 QK12 00MHC10440050 00MHC10440050 IC TC7SH08FU
PM01 QK13 00MHC006105K0 00MHC006105K0 IC TC74VHC541F
T
PM01 QK14 00MHC006105K0 00MHC006105K0 IC TC74VHC541F
T
PM01 QK15 00MBA20035210 00MBA20035210 TRS. DTC114EU
PM01 QK91 00MHC91930210 00MHC91930210 IC BA33BCOWFP
PM01 QK92 00MHC91J18210 00MHC91J18210 IC BA18BCOWFP
PM01 QM01 00MHC10092840 00MHC10092840 IC ADV7324 VIDEO-ENCODER
PM01 QM02 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QM03 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QM04 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QM05 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QM06 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QM07 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QM08 00MHC10440050 00MHC10440050 IC TC7SH08FU
PM01 QM91 00MHC10228210 00MHC10228210 IC BA25BC0WFP 2.5V REG.
PM01 QN01
/
N1S 00D262347800
4
00D262347800
4
IC ADV7320
PM01 QN02
/
N1S 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QN03
/
N1S 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QN04
/
N1S 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QU01 00MHS25AKH20F 00MHS25AKH20F U-PRO HD64F2238RFA13
PM01 QU02 00MHC10431990 00MHC10431990 IC AT24C04N-10SI-1.8
PM01 QU03 00MHC10229210 00MHC10229210 IC BD4727G 2.7V RESET IC
PM01 QU04 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PM01 QU05 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PM01 QU06 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PM01 QU07 00MBA20035210 00MBA20035210 TRS. DTC114EU
PM01 QU08 00MBA20035210 00MBA20035210 TRS. DTC114EU
PM01 QU09 00MBA10026210 00MBA10026210 TRS. DTA114EU
PM01 QU10 00MBA20035210 00MBA20035210 TRS. DTC114EU
PM01 QU15 00MBA20035210 00MBA20035210 TRS. DTC114EU
PM01 QU16 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PM01 QU91 00MHC98203090 00MHC98203090 IC NJU7222U33-TE1 3.3V REG.
PM01 QU92 00MHC10047990 00MHC10047990 IC MAX7315AUE+
T
PM01 R101 ns
p
00MNN05220610 CHIP RES. 22 OHM +-5% 1/16
W
225
