Marantz DV9600 - Page 205

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
PV01 LE03
/
N1S 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LE05
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PV01 LE08
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PV01 LE90
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PV01 LE91
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PV01 LT81 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PV01 LT82 00MFN31000020 00MFN31000020 EMI FILTER BLM11B252SD
PV01 LT83 00MFN31000020 00MFN31000020 EMI FILTER BLM11B252SD
PV01 LT84 00MFN31000020 00MFN31000020 EMI FILTER BLM11B252SD
PV01 LT85 00MFN31000020 00MFN31000020 EMI FILTER BLM11B252SD
PV01 LV01 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LY01 00MLU12102010 00MLU12102010 CHIP INDUCTANCE NL322522-1R0M
PV01 LY02 00MLU12392010 00MLU12392010 CHIP INDUCTANCE NL322522-3R9M
PV01 LY03 00MLU12102010 00MLU12102010 CHIP INDUCTANCE NL322522-1R0M
PV01 LY04 00MLU12392010 00MLU12392010 CHIP INDUCTANCE NL322522-3R9M
PV01 LY05 00MLU12102010 00MLU12102010 CHIP INDUCTANCE NL322522-1R0M
PV01 LY06 00MLU12392010 00MLU12392010 CHIP INDUCTANCE NL322522-3R9M
PV01 LY07 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LY08 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 QE01
/
N1S 00MHC12244090 00MHC12244090 IC NJM2584M 50MHZ VIDEO S
W
PV01 QE02
/
N1S 00MHC10102550 00MHC10102550 IC MM1623XFBE VIDEO AMP
PV01 QE03
/
N1S 00MBA20035210 00MBA20035210 TRS. DTC114EU
PV01 QE04
/
N1S 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PV01 QE05
/
N1S 00MBA20035210 00MBA20035210 TRS. DTC114EU
PV01 QE06
/
N1S 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QT81 00MHC10248990 00MHC10248990 IC ISL83384ECA-
T
PV01 QV01 00MHC10103550 00MHC10103550 IC MM1566AJBE VIDEO AMP WITH LP
F
PV01 QV02 00MBA20035210 00MBA20035210 TRS. DTC114EU
PV01 QV03 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PV01 QV04 00MBA20035210 00MBA20035210 TRS. DTC114EU
PV01 QV91 00MHC91905210 00MHC91905210 IC BA05SFP-E2
PV01 QY01 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PV01 QY02 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QY03 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PV01 QY04 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QY05 00MHX100012A0 00MHX100012A0 CHIP TRS. 2SA1586
(
Y,GR
)
/ 2SA1576A
(
Q,R
)
PV01 QY06 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QY07 00MHC10231090 00MHC10231090 IC NJM2580M-TE1 3CH VIDEO AMP
PV01 QY08 00MBA20035210 00MBA20035210 TRS. DTC114EU
PV01 QY09 00MBA20035210 00MBA20035210 TRS. DTC114EU
PV01 RE01
/
N1S ns
p
00MNN05390610 CHIP RES. 39 OHM +-5% 1/16
W
PV01 RE02
/
N1S ns
p
00MNN05330610 CHIP RES. 33 OHM +-5% 1/16
W
PV01 RE03
/
N1S ns
p
00MNN05390610 CHIP RES. 39 OHM +-5% 1/16
W
PV01 RE04
/
N1S ns
p
00MNN05330610 CHIP RES. 33 OHM +-5% 1/16
W
PV01 RE05
/
N1S ns
p
00MNN05390610 CHIP RES. 39 OHM +-5% 1/16
W
PV01 RE06
/
N1S ns
p
00MNN05330610 CHIP RES. 33 OHM +-5% 1/16
W
PV01 RE07
/
N1S ns
p
00MNN05390610 CHIP RES. 39 OHM +-5% 1/16
W
PV01 RE08
/
N1S ns
p
00MNN05330610 CHIP RES. 33 OHM +-5% 1/16
W
PV01 RE10
/
N1S ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16
W
PV01 RE11
/
N1S ns
p
00MNN05102610 CHIP RES. 1K OHM +-5% 1/16
W
PV01 RE12
/
N1S ns
p
00MNN05563610 CHIP RES. 56K OHM +-5% 1/16
W
PV01 RE13
/
N1S ns
p
00MNN05221610 CHIP RES. 220 OHM +-5% 1/16
W
PV01 RE14
/
N1S ns
p
00MNN05221610 CHIP RES. 220 OHM +-5% 1/16
W
PV01 RE15
/
N1S ns
p
00MNN05221610 CHIP RES. 220 OHM +-5% 1/16
W
PV01 RE16
/
N1S ns
p
00MNN05472610 CHIP RES. 4.7K OHM +-5% 1/16
W
PV01 RE17
/
N1S ns
p
00MNN05472610 CHIP RES. 4.7K OHM +-5% 1/16
W
PV01 RE18
/
N1S ns
p
00MNN05563610 CHIP RES. 56K OHM +-5% 1/16
W
PV01 RE19
/
N1S ns
p
00MNN05152610 CHIP RES. 1.5K OHM +-5% 1/16
W
PV01 RE20
/
N1S ns
p
00MNN05152610 CHIP RES. 1.5K OHM +-5% 1/16
W
PV01 RE21
/
N1S ns
p
00MNN05152610 CHIP RES. 1.5K OHM +-5% 1/16
W
PV01 RE22
/
N1S ns
p
00MNN05105610 CHIP RES. 1M OHM +-5% 1/16
W
PV01 RE23
/
N1S ns
p
00MNN05105610 CHIP RES. 1M OHM +-5% 1/16
W
PV01 RE90
/
N1S ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16
W
PV01 RE91
/
N1S ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16
W
PV01 RE92
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PV01 RE93
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
PV01 RT71 F B ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16
W
239
