Marantz M-CR511 - Specifications

Specifications
o
Audio section
0
Audio amplifier
Rated output: 2-channel driving
50 W + 50 W
(6 Ω/ohms, 1 kHz, THD+N 0.7 %)
Dynamic power: 60 W + 60 W
(6 Ω/ohms, 1 kHz, THD+N 10 %)
Output terminals: Speaker: 4-16 Ω/ohms (impedance)
Compatible with headphones/stereo headphones
Input sensitivity/impedance: Analog In: 200 mV/22 kΩ/kohms
Total harmonic distortion
(1 kHz, 5 W, 6 Ω/ohms):
Analog In: 0.1 %
S/N ratio (10 W, 6 Ω/ohms, IHF-A): Analog In : 90 dB
Tone control: Dynamic Bass Boost : +8 dB (100 Hz)
Bass : ±10 dB (100 Hz)
Treble : ±10 dB (10 kHz)
Frequency response: Analog In : 5 Hz – 40 kHz (±3dB)
