Marantz MM8003 - Page 71

P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
POS. NO.
CPU C407 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C408 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C409 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
CPU C410 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU
C411
00MDK96104300
CER CAP
UF V K
CPU
C411
ns
p
00MDK96104300
CER
.
CAP
.
0.1
UF
50
V
K
CCUS1H104KC
CPU C412 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C413 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C414 ns
p
00MDD95270300 CER. CAP.
27PF 50V JA
CCUS1H270JA
CPU C415 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C416 ns
p
00MOA47601640 ELECT CAP.
47UF 16V
CCEA1CH470T
CPU C417 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C418 ns
p
00MOA47601640 ELECT CAP.
47UF 16V
CCEA1CH470T
CPU C419 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
CPU
C420
nsp
00MDK96103300
CER CAP
0 01UF 50V KC
CCUS1H103KC
CPU
C420
nsp
00MDK96103300
CER
.
CAP
.
0
.
01UF
50V
KC
CCUS1H103KC
CPU C421 ns
p
00MDD95330300 CER. CAP.
33PF 50V JA
CCUS1H330JA
CPU C422 ns
p
00MDD95330300 CER. CAP.
33PF 50V JA
CCUS1H330JA
CPU C423 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C424 ns
p
00MOA47505020 ELECT CAP.
4.7UF 50V
CCEA1HH4R7T
CPU C425 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C426 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C427 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C428 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
CPU C429 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
p
CPU C505 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
CPU CN40 ns
p
ns
p
CONN.
5P STRAIGHT
CJP05GA19ZY
CPU CN41 ns
p
ns
p
CONN.
20 DUAL WAFER
CJP20GA147ZW
CPU CN42 ns
p
ns
p
CONN.
7P WAFER CARD CABLE
CJP07GB113ZY
CPU CN43
/
N1B ns
p
ns
p
CONN.
WAFER 7P
CJP07GA117ZY
CPU CN43
/
U1B ns
p
ns
p
CONN.
WAFER 7P
CJP07GA117ZY
CPU D400 90M-HI200020R 90M-HI200020R L.E.D.
SIR-34ST3F
BVDSIR34ST3F
CPU D401 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
CPU D402 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
CPU D403 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
CPU D404 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
CPU D405 90M-HI101040R 90M-HI101040R L.E.D.
SLR342VCTB7T089
HVD342VCTB7T089
CPU D406 90M-HI101040R 90M-HI101040R L.E.D.
SLR342VCTB7T089
HVD342VCTB7T089
CPU D407 90M-HI101040R 90M-HI101040R L.E.D.
SLR342VCTB7T089
HVD342VCTB7T089
CPU D408 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
CPU IC40 943243001000M 943243001000M U-PRO
R5F21246SNFP MM8003
CVIR5F21246SNFP
CPU 00M47CW499A00 00M47CW499A00 SOFTWARE
FIRMWARE FOR IC40
CPU IC41 943236000650S 943236000650S IC
AT24C04BN-SH-B
CVIAT24C04BNSHB
CPU
IC43
90M HC900050R
90M HC900050R
IC
KIA78D33F
HVIKIA78D33F
CPU
IC43
90M
-
HC900050R
90M
-
HC900050R
IC
KIA78D33F
HVIKIA78D33F
CPU IC44 90M-HW100690R 90M-HW100690R PHOTO UNIT
RPM674CBR-S
CRVRPM6936
CPU IC45 00MHC10099540 00MHC10099540 IC
S-80145ALMC
HVIS-80145ALMC
CPU JK40 90M-YT004860R 90M-YT004860R TERMINAL
3.5MM JACK STEREO
CJJ2D008Z
CPU JK41 90M-YT004860R 90M-YT004860R TERMINAL
3.5MM JACK STEREO
CJJ2D008Z
CPU JK42 90M-YT004860R 90M-YT004860R TERMINAL
3.5MM JACK STEREO
CJJ2D008Z
CPU JK43 943646000850S 943646000850S TERMINAL
CINCH 2P JACK (OR/OR)
CJJ4N076Y
CPU Q400 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
CPU Q401 00MHT30001000 00MHT30001000 TRS.
KTC3199Y
HVTKTC3199YT
C
P
U
Q
4
0
2
00
MHT
3000
1
000
00
MHT
3000
1
000
TR
S
.
KTC3199Y
HVTKTC3199YT
CU
Q0
00 3000 000
00 3000 000
S
CPU Q403 90M-HT600010R 90M-HT600010R TRS.
TKTA1266YT
HVTKTA1266YT
CPU Q404 00MHT600121A0 00MHT600121A0 TRS.
KTA1268GR
HVTKTA1268GRT
CPU Q405 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
CPU Q406 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
CPU R400 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R401 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R402 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R403 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R404 ns
p
00MNN05472610 CHIP RES.
4.7K OHM 1/10W J
CRJ10DJ472T
CPU R405 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
CPU R406 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
CPU R407 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R408 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R409 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R410 ns
p
00MNN05472610 CHIP RES.
4.7K OHM 1/10W J
CRJ10DJ472T
CPU R411 ns
p
00MNN05472610 CHIP RES.
4.7K OHM 1/10W J
CRJ10DJ472T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
