Marantz MM8003 - Page 72

P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
POS. NO.
CPU R413 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R414 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R416 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
CPU R417 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
CPU
R418
00MNN05473610
CHIP RES
K OHM / W J
CPU
R418
ns
p
00MNN05473610
CHIP
RES
.
47
K
OHM
1
/
10
W
J
CRJ10DJ473T
CPU R419 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
CPU R420 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R421 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R422 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R423 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R424 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R425 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R426 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU
R427
nsp
00MNN05103610
CHIP RES
10K OHM 1/10W J
CRJ10DJ103T
CPU
R427
nsp
00MNN05103610
CHIP
RES
.
10K
OHM
1/10W
J
CRJ10DJ103T
CPU R428 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R429 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R430 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
CPU R431 ns
p
00MNN05221610 CHIP RES.
220 OHM 1/10W J
CRJ10DJ221T
CPU R432 ns
p
00MNN05221610 CHIP RES.
220 OHM 1/10W J
CRJ10DJ221T
CPU R433 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
CPU R434 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
CPU R435 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
CPU R436 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
p
CPU R437 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
CPU R438 ns
p
00MNN05183610 CHIP RES.
18K OHM 1/10W J
CRJ10DJ183T
CPU R439 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
CPU R440 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
CPU R441 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
CPU R442 ns
p
00MNN05183610 CHIP RES.
18K OHM 1/10W J
CRJ10DJ183T
CPU R443 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
CPU R444 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
CPU R445 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
CPU R446 ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
CPU R447 ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
CPU R448 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R449 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
CPU R450 ns
p
00MNN05682610 CHIP RES.
6.8K OHM 1/10W J
CRJ10DJ682T
CPU R451 ns
p
00MNN05047610 CHIP RES.
4.7 OHM 1/10W J
CRJ10DJ4R7T
CPU R452 ns
p
00MNN05047610 CHIP RES.
4.7 OHM 1/10W J
CRJ10DJ4R7T
CPU R453 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
CPU R455 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
CPU
R456
nsp
00MNN05561610
CHIP RES
560 OHM 1/10W J
CRJ10DJ561T
CPU
R456
nsp
00MNN05561610
CHIP
RES
.
560
OHM
1/10W
J
CRJ10DJ561T
CPU R457 ns
p
00MNN05561610 CHIP RES.
560 OHM 1/10W J
CRJ10DJ561T
CPU R458 ns
p
00MNN05561610 CHIP RES.
560 OHM 1/10W J
CRJ10DJ561T
CPU R459 ns
p
00MNN05152610 CHIP RES.
1.5K OHM 1/10W J
CRJ10DJ152T
CPU R460 ns
p
00MNN05152610 CHIP RES.
1.5K OHM 1/10W J
CRJ10DJ152T
CPU R463 ns
p
00MNN05104610 CHIP RES.
100K OHM 1/10W J
CRJ10DJ104T
CPU R464 ns
p
00MNN05104610 CHIP RES.
100K OHM 1/10W J
CRJ10DJ104T
CPU R465 ns
p
00MNN05104610 CHIP RES.
100K OHM 1/10W J
CRJ10DJ104T
CPU R466 ns
p
00MNN05104610 CHIP RES.
100K OHM 1/10W J
CRJ10DJ104T
C
P
U
R4
69
n
sp
00
MNN
05
1
5
2
6
1
0
C
HIP RE
S
.
1.5K OHM 1/10W J
CRJ10DJ152T
CU
69
sp
00 05560
CS
CPU R470 ns
p
00MNN05152610 CHIP RES.
1.5K OHM 1/10W J
CRJ10DJ152T
CPU R471 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
CPU R472 F B ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R472
/
K1B ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R473 F B ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU R473
/
K1B ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CPU SW40 90M-SP000880R 90M-SP000880R SW
SW TACT CN
CST1A010Z
CPU SW41 90M-SP001210R 90M-SP001210R SW
SKHV10910G TACT
CST1A012ZT
CPU SW42 90M-SP001210R 90M-SP001210R SW
SKHV10910G TACT
CST1A012ZT
CPU X400 90M-JX001370R 90M-JX001370R X'TAL
16.000MHZ
COX16000E120TF
FAN & PROTECTION PWB
(
CUP12069Y-2
)
FAN/PROT BK72 ns
p
ns
p
BRACKET
BRACKET FOR PWB
CMD1A569
FAN/PROT BK73 ns
p
ns
p
BRACKET
BRACKET FOR PWB
CMD1A569
FAN/PROT BK74 ns
p
ns
p
0
TR HEAT SINK ASSY(CMD1A557)
CVT2SC3419YFA
FAN/PROT BN10 ns
p
ns
p
CORD
2P WIRE ASSY 2.5MM 150MM
CWB1B002150BM
FAN/PROT BN20 ns
p
ns
p
CORD
2P WIRE ASSY 2.5MM 150MM
CWB1B002150BM
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
