Marantz MM8003 - Page 74

P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
POS. NO.
FRONT BN61 ns
p
ns
p
CORD
WIRE ASSY
CWE8102100RV
FRONT C505 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
FRONT C506 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
FRONT C507 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
FRONT
D504
90M HI101190R
90M HI101190R
LED
BLUE LED TOL CSBBCEAB
FRONT
D504
90M
-
HI101190R
90M
-
HI101190R
L
.
E
.
D
.
BLUE
LED
TOL
-52
CSBBCEAB
2
CVD52CSBBCEAB2
FRONT J501 ns
p
ns
p
CORD
SN95/PB5 0.6
C3A206
FRONT J502 ns
p
ns
p
CORD
SN95/PB5 0.6
C3A206
FRONT J503 ns
p
ns
p
CORD
SN95/PB5 0.6
C3A206
FRONT Q503 00MBA10001000 00MBA10001000 TRS.
KRA102M
HVTKRA102MT
FRONT R506 ns
p
ns
p
RES.
120 OHM 1/6W J CARBON
CRD20TJ121T
FRONT R507 ns
p
ns
p
RES.
10K OHM 1/6W J CARBON
CRD20TJ103T
POWER PWB
(
CUP12072Y
)
POWER BN09 ns
p
ns
p
CORD
WIRE ASSY 1PIN 150MM
CWE8102050AA
POWER
BN10
nsp
nsp
CORD
WIRE ASSY
CWE8102180RV
POWER
BN10
nsp
nsp
CORD
WIRE
ASSY
CWE8102180RV
POWER BN11 ns
p
ns
p
CORD
WIRE ASSY 1PIN 80MM TERMINAL
CWE8102080VV
POWER BN13 ns
p
ns
p
CORD
WIRE ASSY 1PIN 50MM TERMINAL
CWE8102050VV
POWER BN15 ns
p
ns
p
CORD
WIRE ASSY 1PIN 150MM TERMINAL
CWE8102150VV
POWER BN20 ns
p
ns
p
CORD
15P WIRE ASSY 2.0MM 400MM
CWB1B015400EN
POWER BN30 ns
p
ns
p
CORD
3P WIRE ASSY 2.0MM 450MM
CWB1B003450BM
POWER BN70 ns
p
ns
p
CORD
WIRE ASSY
CWB1C005150BM
POWER C100 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C101 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C102 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
p
p
POWER C103 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C104 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C105 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C106 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C107 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C108 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C109 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C110 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C111 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C112 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C113 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C114 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C115 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C116 ns
p
ns
p
CER. CAP.
1000PF 50V KB
CCKT1H102KB
POWER C117 ns
p
ns
p
CER. CAP.
1000PF 50V KB
CCKT1H102KB
POWER C118 ns
p
ns
p
CER. CAP.
1000PF 50V KB
CCKT1H102KB
POWER C119 ns
p
ns
p
CER. CAP.
1000PF 50V KB
CCKT1H102KB
POWER C120 ns
p
ns
p
FILM CAP.
0.039UF 100V J
HCQI1H393JZT
POWER
C121
nsp
nsp
FILM CAP
0 039UF 100V J
HCQI1H393JZT
POWER
C121
nsp
nsp
FILM
CAP
.
0
.
039UF
100V
J
HCQI1H393JZT
POWER C122 ns
p
ns
p
FILM CAP.
0.039UF 100V J
HCQI1H393JZT
POWER C123 ns
p
ns
p
FILM CAP.
0.039UF 100V J
HCQI1H393JZT
POWER C124 ns
p
ns
p
FILM CAP.
0.039UF 100V J
HCQI1H393JZT
POWER C125 ns
p
ns
p
FILM CAP.
0.039UF 100V J
HCQI1H393JZT
POWER C126 ns
p
ns
p
FILM CAP.
0.039UF 100V J
HCQI1H393JZT
POWER C127 ns
p
ns
p
FILM CAP.
0.039UF 100V J
HCQI1H393JZT
POWER C128 90M-OF100490R 90M-OF100490R FILM CAP.
0.1UF 250V
KCME2E104JP04T
POWER C129 90M-OF100490R 90M-OF100490R FILM CAP.
0.1UF 250V
KCME2E104JP04T
P
O
WER !
C
1
30
00
M
O
B
5090
711
0
00
M
O
B
5090
711
0
ELE
C
T.
C
AP.
! 50000UF/71V
(
LKGH2503MEYAZT
)
CCET71VLKG503R
O
C 30
00 O 5090 0
00 O 5090 0
CC
()
POWER ! C131 00MOB50907110 00MOB50907110 ELECT. CAP.
! 50000UF/71V(LKGH2503MEYAZT)
CCET71VLKG503R
POWER C132 90M-OF100490R 90M-OF100490R FILM CAP.
0.1UF 250V
KCME2E104JP04T
POWER C133 90M-OF100490R 90M-OF100490R FILM CAP.
0.1UF 250V
KCME2E104JP04T
POWER C134 ns
p
943134000570S ELECT CAP.
KL5 50V/4700UF 25X30 KL5-50V472MS33
CCET50VKL5472NK
POWER C135 ns
p
943134000570S ELECT CAP.
KL5 50V/4700UF 25X30 KL5-50V472MS33
CCET50VKL5472NK
POWER C136 ns
p
00MOA10805020 ELECT CAP.
1000UF/50V
CCEA1HH102E
POWER C137 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C138 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C139 ns
p
00MOA10705020 ELECT CAP.
100UF 50V
CCEA1HH101T
POWER C140 ns
p
00MOA10705020 ELECT CAP.
100UF 50V
CCEA1HH101T
POWER C141 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C142 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
POWER C143 ns
p
00MOA10705020 ELECT CAP.
100UF 50V
CCEA1HH101T
POWER C144 ns
p
00MOA10803520 ELECT CAP.
1000UF 35V
CCEA1VH102E
POWER C145 ns
p
00MOA10803520 ELECT CAP.
1000UF 35V
CCEA1VH102E
POWER C146 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
