Marantz MM8003 - Page 75

P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
POS. NO.
POWER C147 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C148 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
POWER C149 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
POWER C150 ns
p
00MOA10705020 ELECT CAP.
100UF 50V
CCEA1HH101T
POWER
C151
00MOA10705020
ELECT CAP
UF V
POWER
C151
ns
p
00MOA10705020
ELECT
CAP
.
100
UF
50
V
CCEA1HH101T
POWER C152 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
POWER C153 ns
p
ns
p
CER. CAP.
1000PF 50V KB
CCKT1H102KB
POWER C154 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
POWER C155 ns
p
00MOA47701620 ELECT CAP.
470UF 16V ZF
CCEA1CH471T
POWER C156 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
POWER C157 ns
p
00MOA47605020 ELECT CAP.
47UF 50V
CCEA1HH470T
POWER C201 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C202 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER
C203
nsp
nsp
CER CAP
100PF 50V KB
CCKT1H101KB
POWER
C203
nsp
nsp
CER
.
CAP
.
100PF
50V
KB
CCKT1H101KB
POWER C204 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C205 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C206 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C207 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C208 ns
p
ns
p
CER. CAP.
100PF 50V KB
CCKT1H101KB
POWER C209 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
POWER C210 ns
p
00MOA10505020 ELECT CAP.
1UF 50V
CCEA1HH1R0T
POWER CN10 ns
p
ns
p
CONN.
3P WAFER
CJP03GA90ZY
POWER CN11 ns
p
ns
p
CONN.
3P WAFER
CJP03GA90ZY
p
p
POWER CN20 ns
p
ns
p
CONN.
3P WAFER
CJP03GA90ZY
POWER CN21 ns
p
ns
p
CONN.
3P WAFER
CJP03GA90ZY
POWER CN30 ns
p
ns
p
CONN.
A3963WV2-5P (3.96MM)
CJP05GA148ZW
POWER CN40 ns
p
ns
p
CONN.
3P STRAIGHT
CJP03GA01ZY
POWER CN50 ns
p
ns
p
CONN.
3P WAFER
CJP03GA90ZY
POWER CN51 ns
p
ns
p
CONN.
3P WAFER
CJP03GA90ZY
POWER CN60 ns
p
ns
p
CONN.
3P STRAIGHT
CJP03GA01ZY
POWER CN61 ns
p
ns
p
CONN.
3P STRAIGHT
CJP03GA01ZY
POWER CN70 ns
p
ns
p
CONN.
20 DUAL WAFER
CJP20GA147ZW
POWER D100 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D101 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D102 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D103 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D105 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D106 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D108 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D109 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D110 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER
D111
nsp
90M HD201750R
DIODE
1N4003
CVD1N4003SRT
POWER
D111
nsp
90M
-
HD201750R
DIODE
1N4003
CVD1N4003SRT
POWER D112 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D113 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D114 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D115 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D116 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D117 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER ! D118 00MHE20030290 00MHE20030290 DIODE
! D30XBN20 SBD BRIDGE
CVDD30XBN20
POWER D119 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
P
O
WER D12
0
n
sp
00
MHD2
00
4
5
2
90
DI
O
DE
D1NJ10 100V 1A SB
CVDD1NJ10T
O
0
sp
00 00 5 90
O
POWER D121 ns
p
00MHD20045290 DIODE
D1NJ10 100V 1A SB
CVDD1NJ10T
POWER D122 ns
p
00MHD20045290 DIODE
D1NJ10 100V 1A SB
CVDD1NJ10T
POWER D123 ns
p
00MHD20045290 DIODE
D1NJ10 100V 1A SB
CVDD1NJ10T
POWER D124 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
POWER D125 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D126 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D127 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
POWER D128 90M-HD302440R 90M-HD302440R ZENER DIODE
ZJ4.7B 1/2W
CVDZJ4.7BT
POWER D200 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
POWER D201 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
POWER D203 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
POWER D204 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
POWER D205 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
POWER D206 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
POWER D207 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
POWER D208 ns
p
00MHD20015210 DIODE
1SS133T-77
CVD1SS133MT
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
