Marantz PM8200 - Page 16

22
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
P201-LED & TONE
CIRCUIT BOARD
P201-CAPACITORS
C201 4822 122 40617 CER. 0.1
F +80 -20% 50V DD38104010
C202 9965 000 01569 CER. 0.01
F +80 -20% 50V DD38103010
C203 4822 124 90352 ELECT 10
F M 16V OA10601620
C204 4822 124 90352 ELECT 10
F M 16V OA10601620
C205 4822 122 40617 CER. 0.1
F +80 -20%50V DD38104010
C206 4822 124 90406 BIG ELECT FMOH223ZTP16
SUPER
EX22300530
C207 4822 124 90352 ELECT 10
F M 16V OA10601620
C208 9965 000 01569 CER. 0.01
F +80 -20% 50V DD38103010
C209 4822 124 12276 FILM 0.01
F J 100V OF15103540
C210 4822 124 12276 FILM 0.01
F J 100V OF15103540
C254 4822 124 90352 ELECT 10
F M 16V OA10601620
C255 4822 124 11947 ELECT 10
F 16V EQ10601630
P201-RESISTOR
R230 4822 052 10228 2.2
5% 1/6W GG05022160
P201-RESISTORS(COMMON)
R
CARBON FILM FIXED RES.
5% 1/6W : R201-R210 R212
R214-R227 R229 R269 R270
P201-SEMICONDUCTORS
D201 4822 130 32362 DIODE 1SS176/MA165/1SS254
30V 0.1A
HD20002000
D202 4822 130 82421 DIODE 1D3 1A/250V HD20002710
D203 4822 130 82421 DIODE 1D3 1A/250V HD20002710
D204 4822 130 32362 DIODE 1SS176/MA165/1SS254
30V 0.1A
HD20002000
D206
D209
4822 130 32362 DIODE 1SS176/MA165/1SS254
30V 0.1A
HD20002000
Q201 9965 000 09809 MICROPROCESSOR 8BIT
42PIN TMP87CH46N-B0024
HU319JT000
Q202 4822 209 73287 IC LB1630 HC10235030
Q203 4822 130 60839 TRS. 2SC2458 Y OR GR HT324582B0
Q204 4822 130 60839 TRS. 2SC2458 Y OR GR HT324582B0
Q205 4822 130 60839 TRS. 2SC2458 Y OR GR HT324582B0
Q206 4822 130 60588 SEMICON.COMP
DTC114ES/UN4211 10K/10K
BA20001000
Q207 4822 130 60107 TRS. 2SA1048 Y OR GR HT110482B0
Q208 4822 130 61227 SEMICON.COMP
DTA114ES/UN4111 10K/10K
BA10001000
Q209 4822 130 61227 SEMICON.COMP
DTA114ES/UN4111 10K/10K
BA10001000
Q210 4822 130 60588 SEMICON.COMP
DTC114ES/UN4211 10K/10K
BA20001000
P201-MISELLANEOUS
L201 4822 158 60605 FERRITE CORE BEADS
(B-01-RT)
FC90050060
X201 4822 242 72066 SERAMIC VIB. CST8.0MHz
(MT)
FQ08004010
P251-
CON CIRCUIT BOARD
P251-CAPACITORS
C251 9965 000 01318 ELECT 220
F M 10V OA22701020
C252 9965 000 01569 CER. 0.01
F +80% -20%50V DD38103010
C253 9965 000 01318 ELECT 220
F M 10V OA22701020
C601 4822 124 41534 ELECT 10
F M 25V OA10602520
C602 4822 124 41534 ELECT 10
F M 25V OA10602520
C603 9965 000 01581 ELECT 22
F M 25V OA22602520
C604 9965 000 01581 ELECT 22
F M 25V OA22602520
C611 4822 124 41534 ELECT 10
F M 25V OA10602520
C612 4822 124 41534 ELECT 10
F M 25V OA10602520
C613 9965 000 01581 ELECT 22
F M 25V OA22602520
C614 9965 000 01581 ELECT 22
F M 25V OA22602520
C615 4822 124 90365 ELECT 220
F M 25V OA22702520
C616 4822 124 90365 ELECT 220
F M 25V OA22702520
C617 4822 122 31205 CER. 47pF J CH 50V DD15470300
C618 4822 122 31205 CER. 47pF J CH 50V DD15470300
P251-CAPACITORS(COMMON)
C
PLASTIC FILM CAPACITOR
5% 50V : C605-C610
P251-RESISTORS
R263 4822 052 10101 100
5% 1/6W GG05101160
R265 4822 052 10101 100
5% 1/6W GG05101160
R623 4822 111 31001 330 5% 1/6W GG05331160
R624 4822 111 31001 330 5% 1/6W GG05331160
R625 9965 000 09813 VARIABLE 10k
(B)X2
RK14K124
RM01030990
R626 9965 000 09813 VARIABLE 10k
(B)X2
RK14K124
RM01030990
R627 9965 000 09814 VARIABLE 20k
(MN)X2
RK14K124
RM02030570
P251-RESISTORS(COMMON)
R
CARBON FILM FIXED RES.
5% 1/6W : R251-R262 R264
R266-R268 R271 R601-R622
P251-SEMICONDUCTORS
D251
4822 130 11569 L.E.D. HLMF-K200 RED HI10005340
D257
D258 9965 000 09808 L.E.D. SELU1E50CM-S BLUE
LED
HI10039080
D259 4822 130 32362 DIODE 1SS176/MA165/1SS254
30V 0.1A
HD20002000
Q251 4822 209 16735 PHOTO UNIT PNA4655M00HB
IR SENSOR
HW10006020
Q252 4822 130 60107 TRS. 2SA1048 Y OR GR HT110482B0
Q253 4822 130 60839 TRS. 2SC2458 Y OR GR HT324582B0
Q601 4822 209 73064 IC NJM-2068-DD HC10053090
Q602 4822 209 73064 IC NJM-2068-DD HC10053090
P251-MISCELLANEOUS
S251 9965 000 09815 ROTARY SWITCH
SRBV17-F0020-11
SR01070050
P291-INPUT SELECTOR
CIRCUIT BOARD
C291 9965 000 01569 CER. CAP. 0.01
F
+80% -20% 50V
DD38103010
C292 9965 000 01569 CER. CAP. 0.01
F
+80% -20% 50V
DD38103010
S291 4822 273 20368 ROTARY SWITCH SRRSIC SR01120070
P501-VOLUME AMP
CIRCUIT BOARD
P501-CAPACITORS
C503 4822 121 70437 FILM 1000pF J 100V OF15102540
C504 4822 121 70437 FILM 1000pF J 100V OF15102540
C505 4822 124 80543 ELECT 10
F 35V OA10603540
C506 4822 124 80543 ELECT 10
F 35V OA10603540
C507 4822 121 10792 FILM 220pF J 100V OF15221540
C508 4822 121 10792 FILM 220pF J 100V OF15221540
C509 9965 000 09803 FILM 22pF J 630V OF55220560
C510 9965 000 09803 FILM 22pF J 630V OF55220560
C511 9965 000 02015 ELECT 22
F M 25V OA22602540
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
