Marantz PM8200 - Page 17

POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
C512 9965 000 02015 ELECT 22 F M 25V OA22602540
C513
4822 124 90365 ELECT 220 F M 25V OA22702520
C516
C517 4822 124 41534 ELECT 10
F M 25V OA10602520
C518 4822 124 41534 ELECT 10
F M 25V OA10602520
C519 9965 000 01561 MICA 10p
10p
F D 250WV DF31100520
C520 9965 000 01561 MICA F D 250WV DF31100520
C521 4822 124 41543 ELECT 1
F M 50V OA10505020
P501-CAPACITORS(COMMON)
C
PLASTIC FILM CAPACITOR
5% 50V : C501 C502
P501-RESISTORS
R549
4822 111 31001 330 5% 1/6W GG05331160
R552
R553 4822 052 10122 1.2k
5% 1/6W GG05122160
R554 9965 000 09811 VARIABLE 30k
(B)
RK16312MC (9MM)
RM03030580
P501-RESISTORS(COMMON)
R
CARBON FILM FIXED RES.
5% 1/6W : R501-R510
R513-R548 R555 R556 R557
P501-SEMICONDUCTORS
D501
D506
4822 130 32362 DIODE 1SS176/MA165/1SS254
30V 0.1A
HD20002000
D508 4822 130 32362 DIODE 1SS176/MA165/1SS254
30V 0.1A
HD20002000
Q501 4822 209 73064 IC NJM-2068-DD HC10053090
Q502 4822 209 73064 IC NJM-2068-DD HC10053090
Q503 4822 130 60107 TRS. 2SA1048 Y OR GR HT110482B0
Q504 4822 130 60107 TRS. 2SA1048 Y OR GR HT110482B0
Q505
4822 130 60839 TRS. 2SC2458 Y OR GR HT324582B0
Q508
Q509
4822 130 60107 TRS. 2SA1048 Y OR GR HT110482B0
Q512
Q513 4822 130 60839 TRS. 2SC2458 Y OR GR HT324582B0
Q514 4822 130 60839 TRS. 2SC2458 Y OR GR HT324582B0
Q515 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q516 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q517 4822 130 42949 TRS. 2SA970 (GR) OR (BL) HT109702A0
Q518 4822 130 42949 TRS. 2SA970 (GR) OR (BL) HT109702A0
Q519 4822 130 60107 TRS. 2SA1048 Y OR GR HT110482B0
P501-MISCELLANEOUS
L501 9965 000 01576 RELAY MR82-24USR LY20240480
S501 4822 276 13449 PUSH SWITCH SPUN12 SP02012090
P851-AC OUTLET/VOL.SEL.
CIRCUIT BOARD
F851 4822 070 33152 FUSE 3.15 A 250V BS
LISTED/FOR N
FS10315850
P891-POWER SW.
CIRCUIT BOARD
C891 4822 121 43732 FILM CAP. 0.01 F 250V AC DF77103500
S891 4822 276 12647 PUSH SWITCH
ESB-99753V-4 TV-8
SP01011470
P951-HEAD PHONE
CIRUIT BOARD
P951-CAPACITORS
C951 4822 124 12276 FILM 0.01
F J 100V OF15103540
C952 4822 124 12276 FILM 0.01
F J 100V OF15103540
P951-RESISTORS
R951 4822 052 10109 10
5% 1/6W GG05100160
R952 4822 052 10109 10
5% 1/6W GG05100160
P951-MISCELLANEOUS
J951 9965 000 01662 JACK HLJ0540-01-410 BLK YJ01003870
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
23
