Marantz PMD661 Service Manual

58
Q410 : BH7824FVM (SP_AMP)
PIN CONFIGURATION
SUSPEND CTRL
BIAS OUT
BIAS IN
SP IN
SP OUT2
GND
Vcc
SP OUT1
PIN No. PIN Name
1 SUSPEND CTRL
2 BIAL OUT
3 BIAS IN
4SP IN
5 SP OUT1
6 Vcc
7 GND
8 SP OUT2
Q804 : NJU3718AM （シリパラ）
NJU3718AM
P9
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
V
DD
P8
P7
P6
P5
P4
P3
NC
V
SS
P2
P1
CLR
STB
CLK
DATA
P10
P11
P12
P13
P14
V
SS
NC
P15
P16
P17
P18
P19
P20
SO
NJU3718AM
PIN CONFIGURATION
P1
Shift Register
Co
n
t
r
o
ll
e
r
C
ir
cu
i
t
Latch Circuit
P2
P3
P19
P20
DAT
A
CL
K
STB
CLR
SO
BLOCK DIAGRAM

Marantz PMD661 Specifications

General

Recording Format	MP3, WAV
Storage Media	SD/SDHC card
Microphone Input	XLR/TRS combo jack
USB	USB 2.0
Microphone	Built-in stereo microphones
Battery Life	Approximately 4 hours with alkaline batteries
Weight	650 g (without batteries)
Sampling Rate	44.1 kHz, 48 kHz
Bit Rate	32kbps to 320kbps (MP3)
Inputs	2 x XLR microphone inputs, 1 x 1/8" (3.5mm) line input
Outputs	1 x 3.5 mm headphone
Power	4 x AA batteries or AC adapter
