Marantz PMD661 Service Manual

59
No. SYMBOL I/O FUNCTION
1 P9 O
2 P10 O
3 P11 O
4 P12 O
5 P13 O
6 P14 O
Parallel Conversion Data Output Terminals
7 V
SS
- GND
8 NC - Non Connection
9 P15 O
10 P16 O
11 P17 O
12 P18 O
13 P19 O
14 P20 O
Parallel Conversion Data Output Terminals
15 SO O Serial Data Output Terminal
16 DATA I Serial Data Input Terminal
17 CLK I Clock Signal Input Terminal
18
STB
I Strobe Signal Input Terminal
19
CLR
I Clear Signal Input Terminal
20 P1 O
21 P2 O
Parallel Conversion Data Output Terminals
22 V
SS
- GND
23 NC - Non Connection
24 P3 O
25 P4 O
26 P5 O
27 P6 O
28 P7 O
29 P8 O
Parallel Conversion Data Output Terminals
30 V
DD
- Power Supply Terminal (2.4 to 5.5V)
PIN DESCRIPTIONS

Marantz PMD661 Specifications

General

Recording Format	MP3, WAV
Storage Media	SD/SDHC card
Microphone Input	XLR/TRS combo jack
USB	USB 2.0
Microphone	Built-in stereo microphones
Battery Life	Approximately 4 hours with alkaline batteries
Weight	650 g (without batteries)
Sampling Rate	44.1 kHz, 48 kHz
Bit Rate	32kbps to 320kbps (MP3)
Inputs	2 x XLR microphone inputs, 1 x 1/8" (3.5mm) line input
Outputs	1 x 3.5 mm headphone
Power	4 x AA batteries or AC adapter
