Marantz PMD661 Service Manual

69
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, D&M WILL NOT SUPPLY THESE PARTS.
PWB
NAME
SYMBOL QTY
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(D&M)
PART NAME DESCRIPTION
99M17CS510000
P100 MAIN PCB KIT(PMD661) (00MWI17CS1000)
P101 MAIN PCB (00MWI10CS1010)
P101 C001 1 nsp 00MDK5622601Y CER.CAP GRM21BB30J226ME38
P101 C002 1 nsp 00MDK5622601Y CER.CAP GRM21BB30J226ME38
P101 C003 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C005 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C006 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C007 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C008 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C009 1 nsp 00MDK0610320Y CER.CAP 0.01 UF
±
10% B 16V GRM36
P101 C010 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C012 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C013 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C014 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C015 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C016 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C017 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C020 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C021 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C022 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C023 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C024 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C025 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C026 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C027 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C028 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C029 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C030 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C031 1 nsp 132350034506S CER.CAP CK73J0J225KT(1608)
P101 C032 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C033 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C034 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C035 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C036 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C037 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C038 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C039 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C040 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C041 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C042 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C043 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C044 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C045 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C046 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C047 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C048 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C050 1 nsp 00MDK0622220Y CER.CAP 2200PF
±
10%
P101 C051 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C052 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C053 1 nsp 00MDK0622120Y CER.CAP CHIP CAP 220PF B.
±
10% GRM36
P101 C054 1 nsp 00MDK0622120Y CER.CAP CHIP CAP 220PF B.
±
10% GRM36
P101 C055 1 nsp 00MDK0622120Y CER.CAP CHIP CAP 220PF B.
±
10% GRM36
P101 C056 1 nsp 00MDK0622120Y CER.CAP CHIP CAP 220PF B.
±
10% GRM36
P101 C057 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C058 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C059 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C060 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608

Marantz PMD661 Specifications

General

Recording Format	MP3, WAV
Storage Media	SD/SDHC card
Microphone Input	XLR/TRS combo jack
USB	USB 2.0
Microphone	Built-in stereo microphones
Battery Life	Approximately 4 hours with alkaline batteries
Weight	650 g (without batteries)
Sampling Rate	44.1 kHz, 48 kHz
Bit Rate	32kbps to 320kbps (MP3)
Inputs	2 x XLR microphone inputs, 1 x 1/8" (3.5mm) line input
Outputs	1 x 3.5 mm headphone
Power	4 x AA batteries or AC adapter
