Marantz PMD661 Service Manual

70
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, D&M WILL NOT SUPPLY THESE PARTS.
PWB
NAME
SYMBOL QTY
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(D&M)
PART NAME DESCRIPTION
P101 C061 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C062 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C063 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C064 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C065 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C067 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C068 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C070 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C071 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C072 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C073 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C074 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C075 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C076 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C077 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C081 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C202 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C203 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C204 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C205 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C206 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C207 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C208 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C209 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C210 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C211 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C212 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C213 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C214 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C215 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C216 1 nsp 00MDK5610620Y CER.CAP GRM21BB31A106KE18L 10UF
±
10% B 10V
P101 C217 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C218 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C219 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C220 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C221 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C222 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C223 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C224 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C225 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C226 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C227 1 nsp 132350034506S CER.CAP CK73J0J225KT(1608)
P101 C228 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C229 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C230 1 nsp 00MDK9647130Y CER.CAP 470PF (GR39)
P101 C232 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C233 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C234 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C235 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C236 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C237 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C302 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C303 1 nsp 139750001503S ELECT.CAP 100UF/10V NOJD107M010R
P101 C304 1 nsp 139750001503S ELECT.CAP 100UF/10V NOJD107M010R
P101 C305 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C306 1 nsp 00MDK0610220Y CER.CAP 1000 PF
±
10 % B 25V GRM36
P101 C307 1 nsp 00MDK0633120Y CER.CAP 330PF
±
10%
P101 C308 1 nsp 00MDK0610320Y CER.CAP 0.01 UF
±
10 % B 16V GRM36

Marantz PMD661 Specifications

General

Recording Format	MP3, WAV
Storage Media	SD/SDHC card
Microphone Input	XLR/TRS combo jack
USB	USB 2.0
Microphone	Built-in stereo microphones
Battery Life	Approximately 4 hours with alkaline batteries
Weight	650 g (without batteries)
Sampling Rate	44.1 kHz, 48 kHz
Bit Rate	32kbps to 320kbps (MP3)
Inputs	2 x XLR microphone inputs, 1 x 1/8" (3.5mm) line input
Outputs	1 x 3.5 mm headphone
Power	4 x AA batteries or AC adapter
