Marantz PMD661 Service Manual

71
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, D&M WILL NOT SUPPLY THESE PARTS.
PWB
NAME
SYMBOL QTY
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(D&M)
PART NAME DESCRIPTION
P101 C309 1 nsp 00MDK0610320Y CER.CAP 0.01 UF
±
10% B 16V GRM36
P101 C310 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C311 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C312 1 nsp 00MDK0610220Y CER.CAP 1000 PF
±
10% B 25V GRM36
P101 C314 1 nsp 132450033502S CER.CAP CK73J1A225KT(2125)
P101 C315 1 nsp 132450033502S CER.CAP CK73J1A225KT(2125)
P101 C316 1 nsp 00MDK0610320Y CER.CAP 0.01 UF
±
10% B 16V GRM36
P101 C317 1 nsp 00MDK9647130Y CER.CAP 470PF (GR39)
P101 C318 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C319 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C320 1 nsp 00MDK0633120Y CER.CAP 330PF
±
10%
P101 C321 1 nsp 132450033502S CER.CAP CK73J1A225KT(2125)
P101 C322 1 nsp 132450033502S CER.CAP CK73J1A225KT(2125)
P101 C323 1 nsp 00D2572022909 ELECT.CAP CS77B0J220MT(NOJ)
P101 C324 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C325 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C326 1 nsp 00D2572018913 ELECT.CAP CS77B1A470MT(NOJ)
P101 C327 1 nsp 00MDD0568020Y CER.CAP CHIP CAP 68PF CH
±
5% GRM36
P101 C328 1 nsp 00MDK0610320Y CER.CAP 0.01 UF
±
10% B 16V GRM36
P101 C329 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C330 1 nsp 00D2572018913 ELECT.CAP CS77B1A470MT(NOJ)
P101 C331 1 nsp 00MDK5622601Y CER.CAP GRM21BB30J226ME38
P101 C332 1 nsp 00MDK5622601Y CER.CAP GRM21BB30J226ME38
P101 C333 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C334 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C335 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C336 1 nsp 00MDK5622601Y CER.CAP GRM21BB30J226ME38
P101 C337 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C338 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C339 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C340 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C341 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C342 1 nsp 00D2570522906 CER.CAP CK73B0J475KT +1608
P101 C401 1 nsp 00MDK5610620Y CER.CAP GRM21BB31A106KE18L 10UF
±
10% B 10V
P101 C402 1 nsp 00MDK5610620Y CER.CAP GRM21BB31A106KE18L 10UF
±
10% B 10V
P101 C403 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C404 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C405 1 nsp 00MDD0110020Y CER.CAP 10 PF
±
0.5 PF CH 25V
P101 C406 1 nsp 00MDD0110020Y CER.CAP 10 PF
±
0.5 PF CH 25V
P101 C407 1 nsp 00MDK0610220Y CER.CAP 1000 PF
±
10 % B 25V GRM36
P101 C408 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C409 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C410 1 nsp 00MDK9647130Y CER.CAP 470PF (GR39)
P101 C412 1 nsp 00MDD0510120Y CER.CAP 100 PF
±
5% CH 25V
P101 C413 1 nsp 00MDD0510120Y CER.CAP 100 PF
±
5% CH 25V
P101 C414 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C415 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C416 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C417 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C418 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C419 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C420 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C421 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C422 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C423 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C424 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C425 1 nsp 00MDD9510130Y CER.CAP 100 PF
±
5 % CG 50V GR39
P101 C426 1 nsp 00MDD9510130Y CER.CAP 100 PF
±
5 % CG 50V GR39

Marantz PMD661 Specifications

General

Recording Format	MP3, WAV
Storage Media	SD/SDHC card
Microphone Input	XLR/TRS combo jack
USB	USB 2.0
Microphone	Built-in stereo microphones
Battery Life	Approximately 4 hours with alkaline batteries
Weight	650 g (without batteries)
Sampling Rate	44.1 kHz, 48 kHz
Bit Rate	32kbps to 320kbps (MP3)
Inputs	2 x XLR microphone inputs, 1 x 1/8" (3.5mm) line input
Outputs	1 x 3.5 mm headphone
Power	4 x AA batteries or AC adapter
