Marantz PMD661 Service Manual

72
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, D&M WILL NOT SUPPLY THESE PARTS.
PWB
NAME
SYMBOL QTY
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(D&M)
PART NAME DESCRIPTION
P101 C427 1 nsp 00MDD0510120Y CER.CAP 100 PF
±
5% CH 25V
P101 C428 1 nsp 00MDD9510130Y CER.CAP 100 PF
±
5% CG 50V GR39
P101 C429 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C430 1 nsp 00MDD0522020Y CER.CAP 22PF (GRM36)
P101 C431 1 nsp 00MDD0510120Y CER.CAP 100 PF
±
5% CH 25V
P101 C432 1 nsp 00MDD0522020Y CER.CAP 22PF (GRM36)
P101 C433 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C434 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C435 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C436 1 nsp 00MDD0510120Y CER.CAP 100 PF
±
5% CH 25V
P101 C437 1 nsp 00MDD0522020Y CER.CAP 22PF (GRM36)
P101 C438 1 nsp 00MDD0522020Y CER.CAP 22PF (GRM36)
P101 C439 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C440 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C441 1 nsp 00D2572018900 ELECT.CAP CS77B1A100MT(NOJ)
P101 C444 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C445 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C446 1 nsp 00MDK9647130Y CER.CAP 470PF (GR39)
P101 C447 1 nsp 00MDK0622220Y CER.CAP 2200PF
±
10%
P101 C448 1 nsp 139750006508S ELECT.CAP CS77B0J227MT(NOJ)
P101 C449 1 nsp 139750006508S ELECT.CAP CS77B0J227MT(NOJ)
P101 C450 1 nsp 00MDK9610230Y CER.CAP 1000 PF
±
10 % B 50V GR36
P101 C451 1 nsp 00MDK9610230Y CER.CAP 1000 PF
±
10 % B 50V GR36
P101 C452 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C453 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C454 1 nsp 00MDK9647130Y CER.CAP 470PF (GR39)
P101 C455 1 nsp 00MDK0647400Y CER.CAP GRM155B30J474KE18
P101 C456 1 nsp 00D2572022909 ELECT.CAP CS77B0J220MT(NOJ)
P101 C457 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C458 1 nsp 00D2572022909 ELECT.CAP CS77B0J220MT(NOJ)
P101 C459 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C460 1 nsp 00MDK0610320Y CER.CAP 0.01 UF
±
10 % B 16V GRM36
P101 C461 1 nsp 00MDK0610320Y CER.CAP 0.01 UF
±
10 % B 16V GRM36
P101 C462 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C463 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C464 1 nsp 00MDK0647400Y CER.CAP GRM155B30J474KE18
P101 C465 1 nsp 00MDK0633220Y CER.CAP 3300PF
±
10%
P101 C466 1 nsp 00MDK0633220Y CER.CAP 3300PF
±
10%
P101 C467 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C468 1 nsp 00MDK0622220Y CER.CAP 2200PF
±
10%
P101 C469 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C470 1 nsp 00MDK5610620Y CER.CAP GRM21BB31A106KE18L 10UF
±
10% B 10V
P101 C471 1 nsp 00MDK9610230Y CER.CAP 1000 PF
±
10 % B 50V GR36
P101 C472 1 nsp 00MDK9610230Y CER.CAP 1000 PF
±
10 % B 50V GR36
P101 C474 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C475 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C476 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C477 1 nsp 00MDK0610520Y CER.CAP GRM155B30J105KE18
P101 C478 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C479 1 nsp 00MDK0610420Y CER.CAP 0.1 UF
±
10% B 10V
P101 C480 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C481 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36
P101 C482 1 nsp 00MDK5622601Y CER.CAP GRM21BB30J226ME38
P101 C483 1 nsp 00MDK5622601Y CER.CAP GRM21BB30J226ME38
P101 C484 1 nsp 00MDK9647130Y CER.CAP 470PF (GR39)
P101 C485 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C486 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C487 1 nsp 00MNN0500061Y CHIP.RES 0 OHM
±
5% 1/16W
P101 C488 1 nsp 00MDK0647120Y CER.CAP CHIP CAP 470PF B.
±
10% GRM 36

Marantz PMD661 Specifications

General

Recording Format	MP3, WAV
Storage Media	SD/SDHC card
Microphone Input	XLR/TRS combo jack
USB	USB 2.0
Microphone	Built-in stereo microphones
Battery Life	Approximately 4 hours with alkaline batteries
Weight	650 g (without batteries)
Sampling Rate	44.1 kHz, 48 kHz
Bit Rate	32kbps to 320kbps (MP3)
Inputs	2 x XLR microphone inputs, 1 x 1/8" (3.5mm) line input
Outputs	1 x 3.5 mm headphone
Power	4 x AA batteries or AC adapter
