NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
FOR EUR
PART NO.
MZ
PART NAME DESCRIPTION
POS. NO.
REG C930 ns
00MOA22802520 ELECT CAP. 2200UF 25V CCEA1EH222E
REG CN96 ns
ns
CONN. 8P STRAIGHT CJP08GA01ZY
REG CN98 90M-YP100240R 90M-YP100240R CONN. 8P HJP08GB131ZK
REG D904 ns
90M-HD201730R DIODE 1N4003 KVD1N4003ST
REG D905 ns
90M-HD201730R DIODE 1N4003 KVD1N4003ST
REG D906 ns
90M-HD201730R DIODE 1N4003 KVD1N4003ST
REG D907 ns
90M-HD201730R DIODE 1N4003 KVD1N4003ST
REG IC91 90M-HC300650R 90M-HC300650R IC L7812CP HVIL7812CP
REG IC92 90M-HC300660R 90M-HC300660R IC L7912CP HVIL7912CP
REG IC93 90M-HC300680R 90M-HC300680R IC L7805CP HVIL7805CP
REG J901 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG J902 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG J911 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG J912 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG J913 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG J921 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG J922 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG J931 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG J941 ns
ns
CORD SN95/PB5, 0.6 C3A206
REG R912 ns
ns
RES. 15K OHM 1/5W J CRD20TJ153T
REG R913 ns
ns
RES. 15K OHM 1/5W J CRD20TJ153T
TACT PWB
CUP11926Z-9
TACT J801
U1B ns
ns
CORD SN95/PB5, 0.6 C3A206
TACT J802
U1B ns
ns
CORD SN95/PB5, 0.6 C3A206
TACT SW96
U1B ns
90M-SP001210R SW SKHV10910G TACT CST1A012ZT
POWER TRANS. 1 PWB
CUP11926-5
TRANS.1 BN96 ns
ns
CORD WIRE ASSY CWB1C908150BM
TRANS.1 C107 ns
ns
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
TRANS.1 C108 ns
ns
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
TRANS.1 C109 ns
ns
FILM CAP. 0.01UF 50V J HCQI1H103JZT
TRANS.1 C110 ns
ns
FILM CAP. 0.01UF 50V J HCQI1H103JZT
TRANS.1 C111 ns
ns
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
TRANS.1 C112 ns
ns
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
TRANS.1 C117 ns
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
TRANS.1 C118 ns
ns
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
TRANS.1 C119 ns
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
TRANS.1 C120 ns
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
TRANS.1 C121 ns
ns
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
TRANS.1 C122 ns
00MOA10705020 ELECT CAP. 100UF 50V CCEA1HH101T
TRANS.1 C123 ns
00MOA47701620 ELECT CAP. 470UF 16V ZF CCEA1CH471T
TRANS.1 CN14 ns
ns
CONN. 7P STRAIGHT CJP07GA19ZY
TRANS.1 CN99 ns
ns
CONN. 3P STRAIGHT CJP03GA01ZY
TRANS.1 D102 90M-HD302190R 90M-HD302190R ZENER DIODE 30V 1/2W HVDMTZJ30BT
TRANS.1 D104 ns
90M-HD201730R DIODE 1N4003 KVD1N4003ST
TRANS.1 D105 ns
90M-HD201730R DIODE 1N4003 KVD1N4003ST
TRANS.1 D108 ns
90M-HD201730R DIODE 1N4003 KVD1N4003ST
TRANS.1 D111 90M-HD302150R 90M-HD302150R ZENER DIODE 6.8V 1/2W HVDMTZJ6.8BT
TRANS.1 J631 ns
ns
CORD SN95/PB5, 0.6 C3A206
TRANS.1 J632 ns
ns
CORD SN95/PB5, 0.6 C3A206
TRANS.1 Q131 00MHT600141B0 00MHT600141B0 TRS. KTA1271Y HVTKTA1271YT
TRANS.1 R101 ns
ns
RES. 3.3 OHM 1/4W KRD25FJ3R3T
TRANS.1 R104 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R105 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R106 F N ns
90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
TRANS.1 R106
N1B 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
TRANS.1 R106
N1G 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
TRANS.1 R106
N1S 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
TRANS.1 R106
U1B ns
90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R107 F N ns
90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
TRANS.1 R107
N1B 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
TRANS.1 R107
N1G 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
TRANS.1 R107
N1S 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
TRANS.1 R107
U1B ns
90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
TRANS.1 R108 ns
ns
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS.1 R109 ns
ns
RES. 10 OHM 1/5W J CRD20TJ100T
TRANS.1 R110 ns
ns
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS.1 R112 ns
ns
RES. 1.2K OHM 1/5W J CRD20TJ122T
92
