Marantz PS3001 - Page 79

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
TRANS.1 R113 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
POWER TRANS. 2 PWB
(
CUP11926Z-7
)
TRANS.2 C921 ns
p
ns
p
FILM CAP. 0.12UF 100V J HCQI1H124JZT
TRANS.2 C922 ns
p
ns
p
FILM CAP. 0.12UF 100V J HCQI1H124JZT
TRANS.2 C923 ns
p
ns
p
FILM CAP. 0.12UF 100V J HCQI1H124JZT
TRANS.2 C924 ns
p
ns
p
FILM CAP. 0.022UF 100V J HCQI1H223JZT
TRANS.2 C925 ns
p
ns
p
FILM CAP. 0.022UF 100V J HCQI1H223JZT
TRANS.2 C926 ns
p
ns
p
FILM CAP. 0.022UF 100V J HCQI1H223JZT
TRANS.2 C927 ns
p
ns
p
FILM CAP. 0.022UF 100V J HCQI1H223JZT
TRANS.2 C931 ns
p
ns
p
FILM CAP. 0.047UF 100V J HCQI1H473JZT
TRANS.2 C932 ns
p
ns
p
FILM CAP. 0.047UF 100V J HCQI1H473JZT
TRANS.2 CN20 ns
p
ns
p
CONN. MOLEX35313-0310 CJP03GA90ZM
TRANS.2 CN93 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
TRANS.2 D990 ns
p
90M-HD201730R DIODE 1N4003 KVD1N4003ST
TRANS.2 J877 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TRANS.2 J878 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TRANS.2 R997 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS.2 R998 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS.2 RL11 90M-LY000440R 90M-LY000440R RELAY ! GB-2C-D24P CSL4B019ZU
POWER TRANS. 3 PWB
(
CUP11926Z-8
)
TRANS.3 BN21 ns
p
ns
p
CORD WIRE ASSY CWB1E908070MM
TRANS.3 D991 90M-HE200250R 90M-HE200250R DIODE ! GBJ1504 HVDGBJ1504
TRANS.3 J875 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TRANS.3 J876 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TUNER INPUT PWB
(
CUP11928Z-2
)
TUNER C231 F N ns
p
ns
p
CER. CAP. 470PF 50V CCBS1H471KBT
TUNER C232 F N ns
p
ns
p
CER. CAP. 470PF 50V CCBS1H471KBT
TUNER C233 F N ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
TUNER C234 F N ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
TUNER CN25 F N ns
p
ns
p
CONN. 4P WAFER CJP04GA19ZM
TUNER JK96 F N ns
p
90M-YT003180R TERMINAL CINCH 2P AUDIO CJJ4N063Z
TUNER R231 F N ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
TUNER R232 F N ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
TUNER R233 F N ns
p
ns
p
RES. 82K OHM 1/5W J CRD20TJ823T
TUNER R234 F N ns
p
ns
p
RES. 82K OHM 1/5W J CRD20TJ823T
VIDEO PWB
(
CUP11926Z-3
)
VIDEO BK51 ns
p
ns
p
TERMINAL EARTH PLATE CMC1A111
VIDEO C501 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C502 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C503 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C504 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C505 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C506 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C507 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C508 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C509 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C510 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C511 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C512 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C513 ns
p
ns
p
CER. CAP. 68PF 50V HCBS1H680JT
VIDEO C514 ns
p
ns
p
CER. CAP. 68PF 50V HCBS1H680JT
VIDEO C515 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C516 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C517 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C518 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C519 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C520 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C522 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C523 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C524 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C525 ns
p
00MOA47700620 ELECT CAP. 470UF 6.3V ZF CCEA0JH471T
VIDEO C526 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C527 ns
p
00MOA47700620 ELECT CAP. 470UF 6.3V ZF CCEA0JH471T
VIDEO C528 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C529 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
VIDEO C530 ns
p
ns
p
CER. CAP. 0.022UF 50V Z HCBS1H223ZFT
VIDEO C531 ns
p
ns
p
CER. CAP. 0.022UF 50V Z HCBS1H223ZFT
93
