Marantz SA-11S1 - Page 30

1-28
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
DESCRIPTION
5101 C251 ns
p
00MOA10701650 ELECT. CAP. 100 UF 16V ARA
5101 C252 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURATA
5101 C253 ns
p
00MOA10701050 ELECT. CAP. 100UF 10V ARA
5101 C254 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURATA
5101 C255 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
5101 C256 ns
p
00MOA10701650 ELECT. CAP. 100 UF 16V ARA
5101 C257 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURATA
5101 C260 ns
p
00MDK96102300 CERAMIC CAP. 1000 PF +- 10 % B 50V GR36
5101 C261 00MDF95331500 00MDF95331500 CHIP MICA UC342H3300J 330PF 500WV
5101 C262 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C271 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C272 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C276 00MDF95331500 00MDF95331500 CHIP MICA UC342H3300J 330PF 500WV
5101 C277 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C292 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURATA
5101 C293 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURATA
5101 C294 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
5101 C295 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURATA
5101 C296 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURATA
5101 C297 ns
p
00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
5101 C301 00MDF95331500 00MDF95331500 CHIP MICA UC342H3300J 330PF 500WV
5101 C302 00MDF95151500 00MDF95151500 CHIP MICA UC342H1500J 150PF 500WV
5101 C303 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C321 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C322 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C326 00MDF95331500 00MDF95331500 CHIP MICA UC342H3300J 330PF 500WV
5101 C327 00MDF95151500 00MDF95151500 CHIP MICA UC342H1500J 150PF 500WV
5101 C328 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C351 00MDF95331500 00MDF95331500 CHIP MICA UC342H3300J 330PF 500WV
5101 C352 00MDF95151500 00MDF95151500 CHIP MICA UC342H1500J 150PF 500WV
5101 C353 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C371 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C372 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C376 00MDF95331500 00MDF95331500 CHIP MICA UC342H3300J 330PF 500WV
5101 C377 00MDF95151500 00MDF95151500 CHIP MICA UC342H1500J 150PF 500WV
5101 C378 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C402 00MDF91100500 00MDF91100500 CHIP MICA UC232H0100D 10PF 500WV
5101 C403 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C404 00MDF95102510 00MDF95102510 CHIP MICA UC552A1001J 1000PF 100WV
5101 C405 ns
p
00MOA10702540 ELECT. CAP. 100UF 25V ARS
5101 C406 00M75060501P0 00M75060501P0 JUMPER
5101 C421 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C422 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C427 00MDF91100500 00MDF91100500 CHIP MICA UC232H0100D 10PF 500WV
5101 C428 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C429 00MDF95102510 00MDF95102510 CHIP MICA UC552A1001J 1000PF 100WV
5101 C430 ns
p
00MOA10702540 ELECT. CAP. 100UF 25V ARS
5101 C431 00M75060501P0 00M75060501P0 JUMPER
5101 C452 00MDF91100500 00MDF91100500 CHIP MICA UC232H0100D 10PF 500WV
5101 C453 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C454 00MDF95102510 00MDF95102510 CHIP MICA UC552A1001J 1000PF 100WV
5101 C455 ns
p
00MOA10702540 ELECT. CAP. 100UF 25V ARS
5101 C456 00M75060501P0 00M75060501P0 JUMPER
5101 C471 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C472 ns
p
00MOA47701650 ELECT. CAP. 470 UF M 16V ARA
5101 C477 00MDF91100500 00MDF91100500 CHIP MICA UC232H0100D 10PF 500WV
5101 C478 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
5101 C479 00MDF95102510 00MDF95102510 CHIP MICA UC552A1001J 1000PF 100WV
5101 C480 ns
p
00MOA10702540 ELECT. CAP. 100UF 25V ARS
5101 C481 00M75060501P0 00M75060501P0 JUMPER
5101 CN12 ns
p
00MOA10603540 ELECT. CAP. 10 UF 35V ARS
5101 CN15 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURATA
5101 D101 00MHZ20028050 00MHZ20028050 CHIP DIODE 1SS301
5101 D201 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
5101 D202 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TOSHIBA
)
5101 D226 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
5101 D227 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TOSHIBA
)
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
