40
SCLK
MCLK
M4
LRCK
SDATA
AOUTL+
AOUTR+
SERIAL INTERFACE
AND FORMAT SELECT
INTERPOLATION
SOFT MUTE
∆Σ
MODULATOR
DYNAMIC
DE-EMPHASIS
SWITCHED
AOUTL-
AOUTR-
FILT+
FILTER
INTERPOLATION
FILTER
FILTER
MULTI-BIT
∆Σ
MODULATOR
MULTI-BIT
ELEMENT
MATCHING
LOGIC
DYNAMIC
ELEMENT
MATCHING
LOGIC
CAPACITOR-DAC
AND FILTER
SWITCHED
CAPACITOR-DAC
AND FILTER
VREF CMOUTFILT-
VOLTAGE REFERENCE
HARDWARE MODE CONTROL
CLOCK
DIVIDER
(CONTROL PORT)
(AD0/CS)
M3 M2
(AD1/CDIN) (SCL/CCLK)
M1
M0
(SDA/CDOUT)
RESET MUTEC MUTE
Q125 : GXPQ7100(MASK)
QD41/QD61/QD71 : CS4397
66 FJUP_D O Focus jump DOWN signal output
67 FJUP_U O Focus jump UP signal output
68 AVSS 0 Ground terminal (for A/D converter)
69 AVREF I Reference voltage input terminal (for A/D converter)
70 AVDD I power supply terminal (+3.3V) (for A/D converter)
71 XFCMP_L I Layer swicthing monitor signal at the down from refrenc level
72 XFCMP_H I Layer swicthing monitor signal at the up from refrenc level
73 XLIM I Sledge position dedector sw (L=inner)
74 XTCLS I Tray loading inner switch input from the toray loader (L=inner)
75 XTOPN I Tray loading inner switch input from the toray loader (L=open)
76 EDCERR - Not used (open)
77 BUEEMP I MPR2="L", input case of install data for the MPU(FLASH ROM version)
78 EPDA - Not used (open)
79 EPCL - Not used (open)
80 PCRXD I Install data input for MPU chip (internal FLASH ROM TYPE)
81 PCTXD O Install data output for MPU chip (internal FLASH ROM TYPE)
82 FSJP O Start of Layer chenge signal
83 SYNCERR I MPR3="H", input case of install data for the MPU (FLASH ROM version)
84 XDECWR O write strobe signal output for CXD1882R
85 XDECRD O Read strobe signal output for CXD1882R
86 MPR1 I MPR1="H", input case of install data for the MPU (FLASH ROM version)
87 VDD Power supply terminal (+3.3V) (digital system)
88 VSS Ground termina1(digital system)
89 A0 O Address signal output
90 A1 O Address signal output
91 A2 O Address signal output
92 A3 O Address signal output
93 A4 O Address signal output
94 A5 O Address signal output
95 A6 O Address signal output
96 A7 O Address signal output
97 XMODEON O CD/DVD(SACD) RF-bypass/DFT selection signal output (H=CD, L=SACD)
98 LDON O Laser diode on/off control signal output "L" : laser diode off, "H" : laser diode on
99 EJECT- O Tray loader pull-in signal
100 EJECT+ O Tray loader push-out signal
