Marantz SR4300 - Video PCB Parts List

59
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
VIDEO PCB
CV101
OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CV104
CV105 nsp DD95470300 CHIP CAP. 47pF, 50V CC41-0805COG470J500NT ECUV1H470JCN
CV106 nsp DD95470300 CHIP CAP. 47pF, 50V CC41-0805COG470J500NT ECUV1H470JCN
CV107 OA47701020 OA47701020 ELECT. CAP. 470µF,6.3V CD1100J471T5S0611 ECEA0JQE471MB
CV108 nsp DD95470300 CHIP CAP. 47pF, 50V CC41-0805COG470J500NT ECUV1H470JCN
CV109 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV111 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV112 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV113 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0805F104Z500NT ECUV1H104ZFN
CV114 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV115 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV116 OA47701020 OA47701020 ELECT. CAP. 470µF,6.3V CD1100J471T5S0611 ECEA0JQE471MB
CV121 OA47701020 OA47701020 ELECT. CAP. 470µF,6.3V CD1100J471T5S0611 ECEA0JQE471MB
CV122 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CV123 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0805F104Z500NT ECUV1H104ZFN
CV152 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV153 nsp DK96103300 CHIP CAP. 0.01µF, 50V CT41-0805B103K500NT ECUV1H103KBN
CV154 nsp DK96103300 CHIP CAP. 0.01µF, 50V CT41-0805B103K500NT ECUV1H103KBN
CV155 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV156 nsp DK96103300 CHIP CAP. 0.01µF, 50V CT41-0805B103K500NT ECUV1H103KBN
CV157 nsp DK96102300 CHIP CAP. 1000pF, 50V CT41-0805B102K500NT ECUV1H102KBN
CV158 nsp DK96102300 CHIP CAP. 1000pF, 50V CT41-0805B102K500NT ECUV1H102KBN
CV164 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0805F104Z500NT ECUV1H104ZFN
CV169 nsp DK96103300 CHIP CAP. 0.01µF, 50V CT41-0805B103K500NT ECUV1H103KBN
CV170 nsp DK96102300 CHIP CAP. 1000pF, 50V CT41-0805B102K500NT ECUV1H102KBN
CV171
nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0805F104Z500NT ECUV1H104ZFN
CV175
CV200 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV202 OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CV203 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV204 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV214 OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CV215 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CV220 OA47701020 OA47701020 ELECT. CAP. 470µF,6.3V CD1100J471T5S0611 ECEA0JQE471MB
CV223 OA22601620 OA22601620 ELECT. CAP. 22µF, 16V CD1101C220T5S0511 ECEA1CAE220MB
CV224 OA47701020 OA47701020 ELECT. CAP. 470µF,6.3V CD1100J471T5S0611 ECEA0JQE471MB
CV227 OA22601620 OA22601620 ELECT. CAP. 22µF, 16V CD1101C220T5S0511 ECEA1CAE220MB
CV228 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CV229 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0805F104Z500NT ECUV1H104ZFN
CV233 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CV234 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0805F104Z500NT ECUV1H104ZFN
CV235 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CV236 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0805F104Z500NT ECUV1H104ZFN
CV240 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CV241 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0805F104Z500NT ECUV1H104ZFN
GNV1 nsp nsp TERMINAL GND LAG FKV7.725.014
ICV101 HC10210090 HC10210090 IC DMP16 NJM2296M OICNJM2296M
ICV106 HC709405B0 HC709405B0 IC DIP
74HC4094N/
TC74HC4094AP
OIC74HC4094N/
OICTC74HC4094AP
ICV201 HC10210090 HC10210090 IC DMP16 NJM2296M OICNJM2296M
ICV202 HC10210090 HC10210090 IC DMP16 NJM2296M OICNJM2296M
JFV101 nsp nsp FPC CONNECTOR 11Pin,1.25mm FAASE1162 VJS11FC11
JFV201 nsp nsp CONNECTOR 9Pin,2.0mm,UL PH09A-20WE VJS09PH11E
JLV101
nsp nsp JUMPER WIRE JPL0000
JLV202
JRV101 *YT002860R *YT002860R
TERMINAL 3P CINCH
AV3-8.4-14 VJJ01303
JRV102 *YT002840R *YT002840R
TERMINAL 2P CINCH
AV2-8.4 VJJ01203
JRV103 *YT002840R *YT002840R
TERMINAL 2P CINCH
AV2-8.4 VJJ01203
JRV201 *YT002930R *YT002930R S TERMINAL JY-5036 VJJ03506D
JRV202 *YT002920R *YT002920R S TERMINAL S-1 VJJ03506
