Marantz SR4300 - Main PCB Parts List (Part 1)

60
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
JRV203 *YT002920R *YT002920R S TERMINAL S-1 VJJ03506
JV101
nsp nsp JUMPER WIRE JPL0000
JV206
LV102 *FM100090R *FM100090R EMI FILTER 22000pF, 250V, 6A DSS30691F223Z16V ELCF223Z250V
LV103 *FM100090R *FM100090R EMI FILTER 22000pF, 250V, 6A DSS30691F223Z16V ELCF223Z250V
RV101 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV102 *NI001030R *NI001030R CHIP RES.
3.3:,1/10W
RC05K3R3JT ERJ6GEKJ3R3V
RV103 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV104 *NI001030R *NI001030R CHIP RES.
3.3:,1/10W
RC05K3R3JT ERJ6GEKJ3R3V
RV105 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV106 *NI001030R *NI001030R CHIP RES.
3.3:,1/10W
RC05K3R3JT ERJ6GEKJ3R3V
RV107 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV108 *NI001030R *NI001030R CHIP RES.
3.3:,1/10W
RC05K3R3JT ERJ6GEKJ3R3V
RV109 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV110 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV111 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV119
NI05102110 NI05102110 CHIP RES.
1.00k:,1/10W
RC05K1001FT ERJ6GEKF102V
RV122
RV123 NI05472110 NI05472110 CHIP RES.
4.7k:,1/10W
RC05K472JT ERJ6GEKJ472V
RV147
NI05102110 NI05102110 CHIP RES.
1.00k:,1/10W
RC05K1001FT ERJ6GEKF102V
RV151
RV152 NI05472110 NI05472110 CHIP RES.
4.7k:,1/10W
RC05K472JT ERJ6GEKJ472V
RV153 NI05000110 NI05000110 CHIP RES.
0:,1/10W
RC05K000FT ERJ6GEKF000V
RV154 NI05000110 NI05000110 CHIP RES.
0:,1/10W
RC05K000FT ERJ6GEKF000V
RV155 NI05000110 NI05000110 CHIP RES.
0:,1/10W
RC05K000FT ERJ6GEKF000V
RV201 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV202 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV203 *NI001030R *NI001030R CHIP RES.
3.3:,1/10W
RC05K3R3JT ERJ6GEKJ3R3V
RV204 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV205 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV206 NI05000110 NI05000110 CHIP RES.
0:,1/10W
RC05K000FT ERJ6GEKF000V
RV207 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV208 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV209 NI05000110 NI05000110 CHIP RES.
0:,1/10W
RC05K000FT ERJ6GEKF000V
RV210 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV211 NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV212 *NI001030R *NI001030R CHIP RES.
3.3:,1/10W
RC05K3R3JT ERJ6GEKJ3R3V
RV215
NI05750110 NI05750110 CHIP RES.
75:,1/10W
RC05K750JT ERJ6GEKJ750V
RV218
RV220 NI05472110 NI05472110 CHIP RES.
4.7k:,1/10W
RC05K472JT ERJ6GEKJ472V
RV221 NI05472110 NI05472110 CHIP RES.
4.7k:,1/10W
RC05K472JT ERJ6GEKJ472V
DIGITAL/AUDIO PCB
CS01 OA10701020 OA10701020 ELECT. CAP. 100µF,6.3V CD1100J101T5S0511 ECEA0JAE101MB
CS02 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0603F104Z500NT ECUV1H104ZFV
CS03 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0603F104Z500NT ECUV1H104ZFV
CS04 OA10701020 OA10701020 ELECT. CAP. 100µF,6.3V CD1100J101T5S0511 ECEA0JAE101MB
CS05 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0603F104Z500NT ECUV1H104ZFV
CS06 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0603F104Z500NT ECUV1H104ZFV
CS100 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0603F104Z500NT ECUV1H104ZFV
CS103
nsp DD95101300 CHIP CAP. 100pF, 50V CC41-0603COG101J500NT ECUV1H101JCV
CS108
CS109 nsp DD95220300 CHIP CAP. 22pF, 50V CC41-0603COG220J500NT ECUV1H220JCV
CS110 nsp DD95220300 CHIP CAP. 22pF, 50V CC41-0603COG220J500NT ECUV1H220JCV
CS111 nsp DD95101300 CHIP CAP. 100pF, 50V CC41-0603COG101J500NT ECUV1H101JCV
CS112 nsp DD95101300 CHIP CAP. 100pF, 50V CC41-0603COG101J500NT ECUV1H101JCV
CS113 nsp DD95220300 CHIP CAP. 22pF, 50V CC41-0603COG220J500NT ECUV1H220JCV
CS114 nsp DD95220300 CHIP CAP. 22pF, 50V CC41-0603COG220J500NT ECUV1H220JCV
CS115 nsp DD95101300 CHIP CAP. 100pF, 50V CC41-0603COG101J500NT ECUV1H101JCV
