Marantz SR4300 - Main PCB Parts List (Part 5)

64
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
CS851 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0603F104Z500NT ECUV1H104ZFV
CS852 OA10800620 OA10800620 ELECT. CAP. 1000µF,6.3V CD1100J102T5S0811 ECEA0JCE102MB
CS866 nsp DK96104300 CHIP CAP. 0.1µF, 50V CT41-0603F104Z500NT ECUV1H104ZFV
DS1
nsp *HD201690R DIODE 1N4001 ODI1N4001
DS5
DS6
nsp *HD201710R DIODE 1N4148 ODI1N4148
DS9
FS01 *FM100090R *FM100090R EMI FILTER 22000pF, 250V, 6A DSS30691F223Z16V ELCF223Z250V
FS02 *FM100090R *FM100090R EMI FILTER 22000pF, 250V, 6A DSS30691F223Z16V ELCF223Z250V
FS401
*FM100090R *FM100090R EMI FILTER 22000pF, 250V, 6A DSS30691F223Z16V ELCF223Z250V
FS404
GND1 nsp nsp TERMINAL GND LAG FKV7.725.014
GND2 nsp nsp TERMINAL GND LAG FKV7.725.014
ICS01 HC3890809F HC3890809F IC NJM7808FA OICNJM7808FA
ICS02 HC3990809F HC3990809F IC NJM7908FA OICNJM7908FA
ICS03 *HC108180R *HC108180R IC QFP M61516FP OICM61516FP
ICS04
HC10035090 HC10035090 IC DUAL OP-AMP. NJM4558MTE3 OICNJM4558MTE3
ICS07
ICS08 *HC108140R *HC108140R IC AK4529VQ OICAK4529VQ
ICS09
HC10102090 HC10102090 IC NJM2068M OICNJM2068M
ICS12
ICS13 *HC108170R *HC108170R IC CS49326 OICCS49326
ICS14 *HS09AWX0R *HS09AWX0R IC MX29LV040QC-90 OICMX29LV040QC90
ICS15 *HC700490R *HC700490R IC TSSOP 74LCX574MTC OIC74LCX574MTC
ICS16 *HC700490R *HC700490R IC TSSOP 74LCX574MTC OIC74LCX574MTC
ICS17 *HC108160R *HC108160R IC BD4742G OICBD4742G
ICS18 *HU100620R *HU100620R IC FP-100B H8/3026F OICH83026F
ICS19 *HC108130R *HC108130R IC VSOP28 AK4112B OICAK4112B
ICS20 *HC700500R *HC700500R IC NC7WZ04P6 OICNC7WZ04P6
ICS21 HC10003990 HC10003990 IC SOP8 AT24C08 OICBR24C08F
ICS22 *HC108150R *HC108150R IC BD4727G OICBD4727G
ICS23 HC10035090 HC10035090 IC DUAL OP-AMP. NJM4558MTE3 OICNJM4558MTE3
ICS24 *HC700460R *HC700460R IC SOIC 74HCT04D OIC74HCT04D
ICS25 *HC700460R *HC700460R IC SOIC 74HCT04D OIC74HCT04D
ICS26
HZ20007210 HZ20007210 DIODE IMN10 ODIIMN10
ICS29
ICS30 *HC700470R *HC700470R IC SOIC 74LCX00M OIC74LCX00M
ICS31 *HC700480R *HC700480R IC SOIC 74LCX32M OIC74LCX32M
ICS33 HC3891209F HC3891209F IC VOLTAGE REGULATOR 7812FA OICNJM7812FA
ICS35
HZ20007210 HZ20007210 DIODE IMN10 ODIIMN10
ICS38
JFS01 nsp nsp CONNECTOR 11Pin,2.0mm,UL PH11A-20E VJS11PH01E
JFS03 nsp nsp CONNECTOR 12Pin,2.0mm,UL PH12A-20E VJS12PH01E
JFS05 nsp nsp CONNECTOR 9Pin,2.0mm,UL PH09A-20E VJS09PH01E
JFS06 nsp nsp CONNECTOR 10Pin,2.5mm,UL XH10A-25E VJS10XH01E
JFS07 nsp nsp CONNECTOR 8Pin,2.0mm,UL PH8A-20E VJS08PH01E
JFS08 nsp nsp FPC CONNECTOR 11Pin,1.25mm FAASD1162 VJS11FC01
JFS09 nsp nsp FPC CONNECTOR 17Pin,1.25mm FAASD1762 VJS17FC01
JFS10 nsp nsp FPC CONNECTOR 16Pin,1.25mm FAASE1662 VJS16FC11
JFS11 nsp nsp FPC CONNECTOR 15Pin,1.25mm FAASE62 VJS15FC11
JRS01 *YT002880R *YT002880R
TERMINAL 4P CINCH
AV4 -8.4-13 VJJ01403
JRS02 *YT002880R *YT002880R
TERMINAL 4P CINCH
AV4 -8.4-13 VJJ01403
JRS03 *YT002900R *YT002900R
TERMINAL 6P CINCH
AV6 -8.4-13 VJJ01603
JRS04 *YT002880R *YT002880R
TERMINAL 4P CINCH
AV4 -8.4-13 VJJ01403
JRS05 *YT002880R *YT002880R
TERMINAL 4P CINCH
AV4 -8.4-13 VJJ01403
LS801
nsp NN05100610 CHIP RES.
10:1/16W
RC03K100JT ERJ3GSKJ100V
LS804
