Marantz SR4300 - Main PCB Parts List (Part 6)

65
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
LS805
nsp NN05000610 CHIP RES.
0: 1/16W
RC03K000JT ERJ3GSKJ000V
LS808
LS809
nsp NN05100610 CHIP RES.
10: 1/16W
RC03K100JT ERJ3GSKJ100V
LS813
LS814 nsp NN05000610 CHIP RES.
0: 1/16W
RC03K000JT ERJ3GSKJ000V
LS815 nsp NN05000610 CHIP RES.
0: 1/16W
RC03K000JT ERJ3GSKJ000V
LS816
nsp NN05101610 CHIP RES.
100: 1/16W
RC03K101JT ERJ3GSKJ101V
LS819
LS821 nsp NN05000610 CHIP RES.
0: 1/16W
RC03K000JT ERJ3GSKJ000V
LS822 nsp NN05000610 CHIP RES.
0: 1/16W
RC03K000JT ERJ3GSKJ000V
LS823 nsp NN05000610 CHIP RES.
0: 1/16W
RC03K000JT ERJ3GSKJ000V
LS824 nsp NN05101610 CHIP RES.
100: 1/16W
RC03K101JT ERJ3GSKJ101V
LS825 nsp NN05101610 CHIP RES.
100: 1/16W
RC03K101JT ERJ3GSKJ101V
LS831
*FC900300R *FC900300R FERRITE CORE
600:
CBG1608U601/
BGH1608A601/
STBH1608-601
ELVUA601T
LS833
LS839 nsp NN05100610 CHIP RES.
10: 1/16W
RC03K100JT ERJ3GSKJ100V
LS840
nsp NN05330610 CHIP RES.
33: 1/16W
RC03K330JT ERJ3GSKJ330V
LS843
LS844 *FC900300R *FC900300R FERRITE CORE
600:
CBG1608U601/
BGH1608A601/
STBH1608-601
ELVUA601T
LS845 nsp NN05101610 CHIP RES.
100: 1/16W
RC03K101JT ERJ3GSKJ101V
LS846 nsp NN05101610 CHIP RES.
100: 1/16W
RC03K101JT ERJ3GSKJ101V
LS847 nsp NN05100610 CHIP RES.
10: 1/16W
RC03K100JT ERJ3GSKJ100V
LS849
nsp NN05101610 CHIP RES.
100: 1/16W
RC03K101JT ERJ3GSKJ101V
LS854
QS01 BA20081210 BA20081210 SEMICON.COMP DTC144EKAT146 OTRDTC144EKAT146
QS02 *BA001440R *BA001440R SEMICON.COMP DTA144EK OTRDTA144EK
QS03 BA20081210 BA20081210 SEMICON.COMP DTC144EKAT146 OTRDTC144EKAT146
QS04 *BA001440R *BA001440R SEMICON.COMP DTA144EK OTRDTA144EK
QS05 BA20005210 BA20005210 SEMICON.COMP DTC114EK OTRDTC114EK
QS06 BA10023210 BA10023210 SEMICON.COMP SMT3 DTA114EKA OTRDTA114EKA
QS09 BA20081210 BA20081210 SEMICON.COMP DTC144EKAT146 OTRDTC144EKAT146
QS10
BA10023210 BA10023210 SEMICON.COMP SMT3 DTA114EKA OTRDTA114EKA
QS14
QS15 BA20005210 BA20005210 SEMICON.COMP DTC114EK OTRDTC114EK
QS16 BA10023210 BA10023210 SEMICON.COMP SMT3 DTA114EKA OTRDTA114EKA
QS17 BA20005210 BA20005210 SEMICON.COMP DTC114EK OTRDTC114EK
QS20 BA20005210 BA20005210 SEMICON.COMP DTC114EK OTRDTC114EK
QS201
*HX100150R *HX100150R TRANSISTOR 2SC4213 OTR2SC4213
QS208
QS22 *HY200020R *HY200020R TRANSISTOR 2SK2824 OTR2SK2824
QS23 *HY200020R *HY200020R TRANSISTOR 2SK2824 OTR2SK2824
QS301
*HX100150R *HX100150R TRANSISTOR 2SC4213 OTR2SC4213
QS306
RS10
nsp NN05473610 CHIP RES.
47k:,1/16W
RC03K473JT ERJ3GSKJ473V
RS14
RS100 nsp NN05100610 CHIP RES.
10:,1/16W
RC03K100JT ERJ3GSKJ100V
RS101 nsp NN05100610 CHIP RES.
10:,1/16W
RC03K100JT ERJ3GSKJ100V
RS102 nsp NN05102610 CHIP RES.
1K: 1/16W
RC03K100JT ERJ3GSKJ102V
RS103 nsp nsp RES.
4.7:,1/4W RT14-4.7:-T26B
ERD14TJ4R7T
