Marantz SR4300 - Main PCB Parts List (Part 11)

70
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
CN309 OA22801620 OA22801620 ELECT. CAP. 2200µF, 16V CD1101C222S5S1225 ECEA1CFJ222MP
CN310 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CN311 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CN312 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CN313 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CN314 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CN315 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CN316 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CN317 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CN318 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CN401 nsp nsp CERAMIC CAP. 100V 0.010uF CL23B-100V-0.010uF-J-T ECQQ2A103JZ
CN402 nsp nsp CERAMIC CAP. 100V 0.010uF CL23B-100V-0.010uF-J-T ECQQ2A103JZ
CN404 *EX000140R *EX000140R ELECT. CAP. 15000UF, 63V CD293 ECEC1JNV153MR
CN405 *EX000140R *EX000140R ELECT. CAP. 63V,15000UF CD293 ECEC1JNV153MR
CN406 OA47605020 OA47605020 ELECT. CAP. 47µF,50V CD1101H470T5S0611 ECEA1HQE470MB
CN407 nsp nsp CERAMIC CAP. 50V,1000pF,2B4 CT1-50V-06a-2B4-1000pFK ECKR1H102K06B
CN410 OA10803520 OA10803520 ELECT. CAP. 1000µF,35V CD288H1V102S5S1225 ECEQ1VFJ102MP
CN411 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CN412 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CN413 OA10702520 OA10702520 ELECT. CAP. 100µF,25V CD1101E101T5S0611 ECEA1EQE101MB
CN414 OA10803520 OA10803520 ELECT. CAP. 1000µF,35V CD288H1V102S5S1225 ECEQ1VFJ102MP
CN415 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CN416 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CN417 OA10702520 OA10702520 ELECT. CAP. 100µF,25V CD1101E101T5S0611 ECEA1EQE101MB
CN418 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CN501 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CN504 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CN510 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CN601 nsp nsp CERAMIC CAP. 50V,1000pF,2B4 CT1-50V-06a-2B4-1000pFK ECKR1H102K06B
CN603 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CN605 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CN606 OA47405020 OA47405020 ELECT. CAP. 0.47µF, 50V CD1101HR47T5S0511 ECEA1HAER47MB
CN607 OA22705020 OA22705020 ELECT. CAP. 220µF, 50V CD1101H221S5S1016 ECEA1HDH221MP
CN608 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CN609 OA47405020 OA47405020 ELECT. CAP. 0.47µF, 50V CD1101HR47T5S0511 ECEA1HAER47MB
CN610 nsp nsp CERAMIC CAP. 50V,1000pF,2B4 CT1-50V-06a-2B4-1000pFK ECKR1H102K06B
CN611 nsp nsp CERAMIC CAP. 50V,1000pF,2B4 CT1-50V-06a-2B4-1000pFK ECKR1H102K06B
CN701 OA22705020 OA22705020 ELECT. CAP. 220µF, 50V CD1101H221S5S1016 ECEA1HDH221MP
CN801 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
DN101
nsp *HD201710R DIODE 1N4148 ODI1N4148
DN204
DN301
nsp *HD201700R DIODE 1N4002 ODI1N4002
DN304
DN305 *HD302110R *HD302110R ZENER DIODE MTZJT773.0B ODIMTZJ3R0BT77
DN306
nsp *HD201710R DIODE 1N4148 ODI1N4148
DN310
DN401 *HE200320R *HE200320R DIODE BRIDGE DIODE RS604 ZLQRS604
DN402 *HE200320R *HE200320R DIODE BRIDGE DIODE RS604 ZLQRS604
DN404
nsp *HD201690R DIODE 1N4001 ODI1N4001
DN407
DN410 nsp *HD201710R DIODE 1N4148 ODI1N4148
DN411 nsp *HD201710R DIODE 1N4148 ODI1N4148
DN501 nsp *HD201690R DIODE 1N4001 ODI1N4001
DN503 nsp *HD201690R DIODE 1N4001 ODI1N4001
DN504 nsp *HD201690R DIODE 1N4001 ODI1N4001
DN701 nsp *HD201700R DIODE 1N4002 ODI1N4002
DN702 *HD302100R *HD302100R ZENER DIODE MTZJT7730A ODIMTZJ30AT77
DN704 *HD302120R *HD302120R ZENER DIODE MTZJ777.5A ODIMTZJ75AT77
DN801 nsp *HD201710R DIODE 1N4148 ODI1N4148
DN802 nsp *HD201710R DIODE 1N4148 ODI1N4148
