Marantz SR4300 - Main PCB Parts List (Part 12)

71
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
FN301
*FS000970R *FS000970R FUSE 250V,1.6A ,L=21mm 50T 016H(VDE) VSF1R625001D
FN404
ICN101 *HC300470R *HC300470R IC PJ1117CZ-3.3V OICPJ1117CZ3R3V
ICN201 *HC700510R *HC700510R IC TC74HCU04AP OICTC74HCU04AP
ICN301 *HC300470R *HC300470R IC PJ1117CZ-3.3V OICPJ1117CZ3R3V
ICN302 HC3890509F HC3890509F IC VOLTAGE REGULATOR 7805FA OICNJM7805FA
ICN303 HC3890509F HC3890509F IC VOLTAGE REGULATOR 7805FA OICNJM7805FA
ICN304 HC3990509F HC3990509F IC VOLTAGE REGULATOR 7905FA OICNJM7905FA
ICN401 HC3891509F HC3891509F IC VOLTAGE REGULATOR 7815FA OICNJM7815FA
ICN402 HC3991509F HC3991509F IC VOLTAGE REGULATOR 7915FA OICNJM7915FA
ICN601 HC10042050 HC10042050 IC SIP TA7317P OICTA7317P
JFN101 nsp nsp FPC CONNECTOR 16Pin,1.25mm FAASD1662 VJS16FC01
JFN102 nsp nsp CONNECTOR 5Pin,2.5mm, UL XH5A-25E VJS05XH01E
JFN301 nsp nsp CONNECTOR 6Pin,2.5mm, UL XH6A-25E VJS06XH01E
JFN401 nsp nsp CONNECTOR 3Pin,8.0mm,UL VH05A2-80E VJS03TH01E
JFN507 nsp nsp CONNECTOR 9Pin,2.0mm,UL PH09A-20E VJS09PH01E
JFN508 nsp nsp CONNECTOR 10Pin,2.5mm,UL XH10A-25E VJS10XH01E
JFN509 nsp nsp CONNECTOR 4Pin,3.96mm,UL VH4A-40E VJS04VH01E
JFN510 nsp nsp CONNECTOR 3Pin,4.0mm,UL VH03A-40E VJS03VH01E
JFN511 nsp nsp CONNECTOR 3Pin,4.0mm,UL VH03A-40E VJS03VH01E
JFN512 nsp nsp CONNECTOR 2Pin,2.0mm,UL PH02-20A VJS02PH01E
JFN601 nsp nsp CONNECTOR 4Pin,2.0mm,UL PH4A-20E VJS04PH01E
JFN701 nsp nsp CONNECTOR 4Pin,2.5mmUL XH4A-25W VJS04XH01E
JFN702 nsp nsp CONNECTOR 7Pin,2.5mm,UL XH7A-25E VJS07XH01E
JN101
nsp nsp JUMPER WIRE JPL0000
JN192
JN501
*YT003000R *YT003000R CONNECTOR 4Pin WP4-10B VJJ05401
JN504
JRN101 *YT002850R *YT002850R
TERMINAL 2P CINCH
VJJ01208
JRN201 *YJ002600R *YJ002600R OPT. CONNECTOR GP1FA550RZ OPGGP1FA550RZ
JRN202 *YJ002600R *YJ002600R OPT. CONNECTOR GP1FA550RZ OPGGP1FA550RZ
JRN203 *YT002870R *YT002870R
TERMINAL 3P CINCH
AV3-8.4-14 VJJ01319
JRN204 YJ15000110 YJ15000110 OPT. CONNECTOR TOTX178 OPTTTOTX178
LN701 *LC107300R *LC107300R INDUCTOR 10µH LGA0307-10UH-K-T26B ELEPS100K01
LN702 *LC107300R *LC107300R INDUCTOR 10µH LGA0307-10UH-K-T26B ELEPS100K01
LN703 *LC107300R *LC107300R INDUCTOR 10µH LGA0307-10UH-K-T26B ELEPS100K01
QN301 *HX300080R *HX300080R TRANSISTOR 2SC5248E OTR2SC5248E
QN401 *HT800020R *HT800020R TRANSISTOR 9014C OTR9014C
QN402 *HT800020R *HT800020R TRANSISTOR 9014C OTR9014C
QN403 *HT800020R *HT800020R TRANSISTOR 9015C OTR9015C
QN601 *HT800020R *HT800020R TRANSISTOR 9014C OTR9014C
QN606 BA20001000 BA20001000 SEMICON.COMP DTC114ESA OTRDTC114ESA
QN607 BA20001000 BA20001000 SEMICON.COMP DTC114ESA OTRDTC114ESA
QN608 *HT800020R *HT800020R TRANSISTOR 9014C OTR9014C
QN609 *HT800020R *HT800020R TRANSISTOR 9014C OTR9014C
QN701 *HT800030R *HT800030R TRANSISTOR KTA1024Y OTRKTA1024Y
QN801 *HT100670R *HT100670R TRANSISTOR 2SC2389RS OTR2SC2389RS
QN802 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
QN803 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
QN804 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
REN501 *LY000320R *LY000320R RELAY JZC42F0242HS VSYJZC42F0242HS
REN503 *LY000320R *LY000320R RELAY JZC42F0242HS VSYJZC42F0242HS
REN504 *LY000320R *LY000320R RELAY JZC42F0242HS VSYJZC42F0242HS
RN101 nsp nsp RES.
220:,1/6W RT13-220:-T26B
ERD16TJ221T
RN102 nsp nsp RES.
47:,1/6W RT13-47:-T26B
ERD16TJ470T
RN103 nsp nsp RES.
47k:,1/6W RT13-47K:-T26B
ERD16TJ473T
RN201 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RN202 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RN203 nsp nsp RES.
75:,1/6W RT13-75:-T26B
ERD16TJ750T
RN204 nsp nsp RES.
75:,1/6W RT13-75:-T26B
ERD16TJ750T
RN205 nsp nsp RES.
75:,1/6W RT13-75:-T26B
ERD16TJ750T
RN206 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
