Marantz SR4300 - Front PCB Parts List

72
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
RN207 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RN208 nsp nsp RES.
1:,1/6W RT13-1:-T26B
ERD16TJ010T
RN209 nsp nsp RES.
100k:,1/6W RT13-100K:-T26B
ERD16TJ104T
RN210 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RN211 nsp nsp RES.
100k:,1/6W RT13-100K:-T26B
ERD16TJ104T
RN212 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RN213 nsp nsp RES.
27:,1/6W RT13-27:-T26B
ERD16TJ270T
RN214 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RN301 nsp nsp RES.
220:,1/2W RT15-220:-T52
ERD12TJ221V
RN402
nsp nsp RES.
15k:,1/6W RT13-15K:-T26B
ERD16TJ153T
RN405
RN406 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RN407 nsp nsp RES.
33k:,1/6W RT13-33K:-T26B
ERD16TJ333T
RN408 nsp nsp RES.
100k:,1/6W RT13-100K:-T26B
ERD16TJ104T
RN415 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RN416 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RN417 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RN501 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RN503 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RN504 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RN601 nsp nsp METAL FILM RES.
330:,3W M0-330:-J-3W
ERYC03J331B
RN602 nsp nsp METAL FILM RES.
330:,3W M0-330:-J-3W
ERYC03J331B
RN603 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RN604 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RN611 nsp nsp RES.
51k:,1/6W RT13-51K:-T26B
ERD16TJ513T
RN612 nsp nsp RES.
100k:,1/6W RT13-100K:-T26B
ERD16TJ104T
RN613 nsp nsp RES.
100k:,1/6W RT13-100K:-T26B
ERD16TJ104T
RN614 nsp nsp RES.
15k:,1/6W RT13-15K:-T26B
ERD16TJ153T
RN615 nsp nsp RES.
30k:,1/6W RT13-30K:-T26B
ERD16TJ303T
RN616 nsp nsp RES.
33k:,1/6W RT13-33K:-T26B
ERD16TJ333T
RN617 nsp nsp RES.
56k:,1/6W RT13-56K:-T26B
ERD16TJ563T
RN618 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RN619 nsp nsp RES.
33k:,1/6W RT13-33K:-T26B
ERD16TJ333T
RN620
nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RN623
RN701 nsp nsp METAL FILM RES.
0.51:,1W M0-0.51:-J-1W
ERYC01JR51B
RN702 nsp nsp RES.
47:,1/2W RT15-47:-T52
ERD12TJ470V
RN703 nsp nsp RES.
1.8k:,1/6W RT13-1.8K:-T26B
ERD16TJ182T
RN801 nsp nsp RES.
7.5k:,1/6W RT13-7.5K:-T26B
ERD16TJ752T
RN802 nsp nsp RES.
7.5k:,1/6W RT13-7.5K:-T26B
ERD16TJ752T
RN803 nsp nsp RES.
2.7k:,1/6W RT13-2.7K:-T26B
ERD16TJ272T
RN804 nsp nsp RES.
2.7k:,1/6W RT13-2.7K:-T26B
ERD16TJ272T
RN805 nsp nsp JUMPER WIRE JPL0000
RN806 nsp nsp RES.
2.7k:,1/6W RT13-2.7K:-T26B
ERD16TJ272T
RN807 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RN808 nsp nsp RES.
390:,1/6W RT13-390:-T26B
ERD16TJ391T
RN809 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RN810 nsp nsp CEMENT RES.
0.1 :, 5W RX27-6-5W-0.1:
ERBGR10J05
RN811 nsp nsp CEMENT RES.
0.1 :, 5W RX27-6-5W-0.1:
ERBGR10J05
RN812 nsp nsp RES.
560k:,1/6W RT13-560K:-T26B
ERD16TJ564T
TRN201 *TP000060R *TP000060R PULSE TRANSF. 4203, 6m¥m 6AL-158AO EIS6AL158AO
FRONT PCB
CF101 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF102 nsp nsp CERAMIC CAP. 50V,47pF,SL CC1-50V-06a-SL-47pFJ ECCR1H470JY
CF103 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF104 nsp nsp CERAMIC CAP. 50V,1000pF,2B4 CT1-50V-06a-2B4-1000pFK ECKR1H102K06B
CF105
nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF109
CF110 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
