Marantz SR4300 - Front PCB Parts List (Continued)

73
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
CF111 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF112 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF113 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF114 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CF115 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF116 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CF117 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF118 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF119 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF120 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CF121 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CF122 OA47601640 OA47601640 ELECT. CAP. 16V, 47µF CD1101C470T5S0511 ECEA1CAE470MB
CF123 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF124 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF125 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF126 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CF127 nsp nsp CERAMIC CAP. 50V,10000pF,2F4 CT1-50V-08a-2F4-10000pFZ ECKR1H103Z08F
CF128
nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CF134
ICF101 *HC108190R *HC108190R IC LQFP PT6302-001 OICPT6302001
IRF102 *HW100640R *HW100640R IR SENSOR
PIC12042/
TSOP1838-16
RPMPIC12042/
RPMPIC12042D
JF102 nsp nsp FPC CONNECTOR 15Pin,1.25mm FAASE62 VJS15FC11
JFF101 nsp nsp CONNECTOR 7Pin,2.5mm,UL XH7A-25E VJS07XH01E
JFF103 nsp nsp CONNECTOR 4Pin,2.0mm,UL PH4A-20E VJS04PH01E
JFF104 nsp nsp CONNECTOR 4Pin,2.0mm,UL PH4A-20E VJS04PH01E
JPF101
nsp nsp JUMPER WIRE JPL0000
JPF164
QF101 BA10007210 BA10007210 SEMICON.COMP DTA114ES OTRDTA114ES
QF102 BA10007210 BA10007210 SEMICON.COMP DTA114ES OTRDTA114ES
QF103 HT317401L0 HT317401L0 TRANSISTOR 2SC1740STPR/2SC1740-R OTR2SC1740S
QF104 BA10012210 BA10012210 SEMICON.COMP DTC144ESA OTRDTC144ESA
RF101 nsp nsp RES.
3.3k:,1/6W RT13-3.3K:-T26B
ERD16TJ332T
RF102 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RF103 nsp nsp RES.
8.2k:,1/6W RT13-8.2K:-T26B
ERD16TJ822T
RF104 nsp nsp RES.
3.9k:,1/6W RT13-3.9K:-T26B
ERD16TJ392T
RF105 nsp nsp RES.
1.8k:,1/6W RT13-1.8K:-T26B
ERD16TJ182T
RF106 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RF108 nsp nsp RES.
3.9k:,1/6W RT13-3.9K:-T26B
ERD16TJ392T
RF109 nsp nsp RES.
1.2k:,1/6W RT13-1.2K:-T26B
ERD16TJ122T
RF110 nsp nsp RES.
1.8k:,1/6W RT13-1.8K:-T26B
ERD16TJ182T
RF111 nsp nsp RES.
1.2k:,1/6W RT13-1.2K:-T26B
ERD16TJ122T
RF112 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RF113 nsp nsp RES.
8.2k:,1/6W RT13-8.2K:-T26B
ERD16TJ822T
RF114 nsp nsp RES.
3.9k:,1/6W RT13-3.9K:-T26B
ERD16TJ392T
RF115 nsp nsp RES.
1.8k:,1/6W RT13-1.8K:-T26B
ERD16TJ182T
RF116 nsp nsp RES.
1.2k:,1/6W RT13-1.2K:-T26B
ERD16TJ122T
RF117 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RF118 nsp nsp RES.
8.2k:,1/6W RT13-8.2K:-T26B
ERD16TJ822T
RF119 nsp nsp RES.
3.9k:,1/6W RT13-3.9K:-T26B
ERD16TJ392T
RF120 nsp nsp RES.
1.8k:,1/6W RT13-1.8K:-T26B
ERD16TJ182T
RF121 nsp nsp RES.
1.2k:,1/6W RT13-1.2K:-T26B
ERD16TJ122T
RF122 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RF123 nsp nsp RES.
330:,1/6W RT13-330:-T26B
ERD16TJ331T
RF124 nsp nsp RES.
330:,1/6W RT13-330:-T26B
ERD16TJ331T
RF125
nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RF129
RF130 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
SWF101
*SP001200R *SP001200R PUSH SWITCH 4Pin EVQPAE05R EVQ21505K
SWF122
